Airtac APC Threaded Quick Connect Coupling APC4-M5
Type: Male Threaded Straight Connector , Brand: Airtac , Series: APC
AirTAC APC4-M5 Threaded Quick Connector Specifications
- Model: APC4-M5
- Type: Push-to-connect threaded fitting
- Thread Standard: M5×0.8 external thread (male)
- Material: Nickel-plated brass body, PPSU/POM sleeve
- Tube Compatibility: 4mm OD pneumatic tubing
- Max Working Pressure: 1.0 MPa (145 psi)
- Temperature Range: -20℃ to 80℃ (continuous use)
- Seal Material: High-grade NBR rubber
- IP Rating: IP40 (dust protected)
- Vibration Resistance: ≤10 Hz @ 2mm amplitude
- Weight: 4.2g ±0.3g
- Dimensions: 19.5mm(L) × 12mm(W) × 12mm(H)
- Certifications: RoHS compliant, ISO 16030 standard
Precision-engineered quick-disconnect coupling featuring a leak-proof double-locking mechanism with visual connection confirmation window. The chrome-plated brass construction ensures corrosion resistance in humid environments, while the 360° rotatable design prevents tube twisting during machine operation.
- Modular pneumatic tool connections
- 3D printer filament feed systems
- Laboratory gas chromatography setups
- Robotic arm end-effector tooling
- HVAC refrigerant line service ports
Installation protocol:
For optimal sealing, insert tube until it bottoms out (audible click).
Always perform pull-out test with 5kgf minimum force. Lubricate threads
with PTFE tape when mating with aluminum components.
Not compatible with petroleum-based fluids or hydraulic oils.
Maximum 5000 mating cycles at full pressure. Replace O-rings
every 2 years under continuous operation.
| Property | Property Value |
|---|---|
| sku | APC4-M5 |
| Insert Tube | <4mm> |
| Threaded Port | M5 |
