Airtac APL L-type Elbow Fitting APL4-01
2、Superior flow performance achieves throughput equivalent to the inner diameter of connected tubing;
3、Features plug-and-play convenience with secure and durable tubing connections;
4、Threads pre-coated with sealing compound, M5 metric threads incorporate sealing gasket for leak-free threaded connections;
5、Nickel-plated brass body provides enhanced resistance to corrosion and contamination, expanding application scope.
Category: L-Type Elbow Fitting , Brand: AIRTAC , Series: APL
AirTAC APL L-Type Elbow Fitting APL4-01 Technical Details
- Model: APL4-01 (L-Type 90° Elbow)
- Thread Standard: Metric (M5×0.8) & Tube OD 4mm
- Material: Nickel-plated brass (CuZn39Pb3)
- Seal Material: HNBR rubber (high nitrile)
- Max Working Pressure: 1.0 MPa (145 psi)
- Proof Pressure: 1.5 MPa
- Burst Pressure: ≥3.0 MPa
- Temperature Range: -20℃ to 80℃ (-4°F to 176°F)
- Surface Finish: Electro-less nickel plating (3-5μm)
- Weight: 8.2 grams (0.29 oz)
- Dimensions: 18mm (L) × 16mm (W) × 16mm (H)
- Thread Engagement: 5.5mm minimum
- Fluid Compatibility: Air, inert gases, moisture-free oil mist
- Vibration Resistance: ≤10Hz @ 2mm amplitude
- Certification: RoHS compliant
Precision-engineered L-shaped pneumatic connector featuring a 90° flow path for space-constrained installations. The dual-seal design combines metal-to-metal thread contact with elastic sealing for leak-free performance. Optimized internal bore (2.8mm ID) minimizes pressure drop while maintaining structural integrity.
- Pneumatic cylinder port redirection in robotic arms
- Compact valve manifolds for packaging machinery
- Air tool hose-to-body connections
- Medical device pneumatic circuit routing
- Laboratory equipment gas line configurations
Installation protocol:
Apply 1.5-2N·m torque during assembly. Use thread sealant only on male ports,
avoiding contamination of sealing surfaces. For push-to-connect models,
insert tubing perpendicularly until audible click.
