Airtac APX Y-Type Tee Fitting APX10-M20
2. Comprehensive model range with multiple specifications, engineered for versatile integration across pneumatic systems;
3. Optimized flow dynamics achieve full-bore performance matching tubing inner diameter capacity;
4. Tool-free push-to-connect mechanism enables rapid installation/removal, with robust tubing retention for secure long-term operation.
Category: Y-Type Tee Fittings | Brand: AirTAC | Series: APX
AirTAC APX Series Y-Type Tee Connector APX10-M20 Technical Details
- Model: APX10-M20
- Type: Y-shaped triple port pneumatic connector
- Body material: CNC-machined brass (CuZn39Pb3)
- Thread specifications: M20×1.5 male threads (all ports)
- Pressure rating: 0.3-1.2 MPa (43-174 PSI)
- Burst pressure: ≥3.0 MPa
- Temperature range: -20℃ to 150℃ (with FKM seals)
- Seal material: Standard NBR, optional FKM/Viton®
- Surface treatment: Electroless nickel plating (8-12μm)
- Weight: 68g ±2g
- Dimensions: 38mm (L) × 32mm (W) × 28mm (H)
- Flow coefficient (Cv): 0.45
- Leakage rate: <0.1 NL/min under 0.5 MPa
High-flow Y-divider featuring triple-port symmetrical design with unified M20 threads, optimized for balanced pressure distribution in pneumatic systems. Precision-machined internal channels reduce turbulence by 18% compared to standard tees. Compatible with ISO 1179-1 and DIN 3852 standards.
- Pneumatic circuit branching in CNC machine tools
- Compressed air distribution in packaging lines
- Multi-actuator control systems for automation cells
- Air amplifier systems in material handling
- Test bench pneumatic networks
Installation protocol:
Apply PTFE tape on male threads using clockwise winding pattern.
Tighten to 25-30 N·m torque using flank-contact wrench.
Avoid thread compound contamination in flow paths.
| Property | Property Value |
|---|---|
| sku | APX10-M20 |
