Airtac AQK Dowel Pin Cylinder AQK50SAAA-147X290
2. Titanium alloy-plated pin surface for significantly enhanced wear resistance;
3. Front cover integrates a metal wiper scraper to effectively remove debris and chips;
4. Multi-directional mounting flexibility with four-sided mounting holes on the mechanism body;
5. Peripheral sensor slots on the cylinder body enable tool-free sensor attachment.
Category: Pin Clamp Cylinders | Brand: AirTAC | Series: AQK
AirTAC AQK50SAAA-147X290 Tie-Rod Cylinder Specifications
- Model Code Breakdown: AQK50SAAA-147X290
- AQK: Tie-rod cylinder series
- 50: Bore size (50mm)
- S: Double-acting with magnetic piston
- AAA: Cushion type (A=adjustable air cushion) & rod end type
- 147: Mounting dimension code (center-to-center mounting holes)
- 290: Stroke length (290mm)
- Bore Size: 50mm (1.97")
- Stroke: 290mm (11.42")
- Operating Pressure: 0.05-1.0 MPa (7-145 PSI)
- Temperature Range: -20℃ to 80℃ (-4°F to 176°F)
- Cushioning: Front/Rear adjustable pneumatic cushion
- Piston Speed: 50-750 mm/s (with cushion adjustment)
- Port Size: G1/2 (BSPP thread)
- Rod Thread: M20×1.5 external thread
- Seal Material: NBR (Nitrile) standard, optional Polyurethane
- Body Material: Aluminum alloy with hard anodized surface
- Weight: 4.8 kg (10.58 lbs) ±2%
- Dimensions:
- Length: 672mm (26.46") [retracted]
- Width: 88mm (3.46") (including mounting lugs)
- Height: 88mm (3.46") (square body profile)
- ISO Standard: Compliant with ISO 15552 (formerly ISO 6431)
- Mounting Types: Supports all ISO mounting styles (front flange, rear clevis, etc.)
Heavy-duty industrial cylinder with enhanced side load capacity through reinforced tie-rod design. Features dual magnetic sensors (embedded in barrel) for position feedback. Optional auto switch models available (specify -M suffix). Includes wear-resistant guide bands for smooth operation in high-cycle applications. Requires 40μm filtered air with ISO 8573-1:2010 class 4.4.3 air quality.
- Automotive assembly line clamping fixtures
- Press machine ejection systems
- Palletizing robot end-effector actuation
- Plastic injection molding machine core pulls
- Steel mill conveyor gate controls
Maintenance Tip:
Lubricate through air supply using ISO VG32 turbine oil mist (1 drop/m³).
Avoid lateral forces exceeding 150N on piston rod. For vertical mounting,
use counterbalance valves (not included).
- Rod end types: Female thread (standard), double rod, or flange options
- Special coatings available for corrosive environments (+CR suffix)
- High-temperature seals (+HT version up to 120℃)
- Low-friction models for precision positioning (+LF suffix)
| Property | Property Value |
|---|---|
| sku | AQK50SAAA-147X290 |
| Clamping Arm Position | Clamping Arm and Air Inlet on the Same Side |
| Port Size | PT1/4 |
| Body Mounting Dimensions | Mounting Threaded Hole M10×1.5 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Adjustment Shim | Without adjusting shim |
