Airtac AQK Dowel Pin Cylinder AQK50SAAA-149X290
2. Titanium alloy-plated pin surface for significantly enhanced wear resistance;
3. Front cover integrates a metal wiper scraper to effectively remove debris and chips;
4. Multi-directional mounting flexibility with four-sided mounting holes on the mechanism body;
5. Peripheral sensor slots on the cylinder body enable tool-free sensor attachment.
Category: Pin Clamp Cylinders | Brand: AirTAC | Series: AQK
AirTAC AQK50SAAA-149X290 Rodless Cylinder Specifications
- Model: AQK50SAAA-149X290
- Series: AQK-S Standard Type
- Bore size: Ø50 mm
- Stroke: 290 mm (adjustable ±1mm)
- Operating pressure: 0.1–0.9 MPa
- Cushioning: Adjustable pneumatic cushion
- Mounting type: Standard foot mounting (MF1)
- Port size: 1/4" NPT (G1/4 optional)
- Piston speed: 50–800 mm/s
- Ambient temperature: -20℃ to 80℃
- Material: Aluminum alloy barrel, chrome-plated piston rod
- Seal material: NBR (nitrile rubber)
- Protection rating: IP65
- Weight: 3.5 kg ±2%
- Dimensions (L×W×H): 525mm × 62mm × 62mm (including accessories)
Precision-engineered rodless cylinder with dual-slot magnetic coupling design, featuring zero leakage and smooth linear motion. The anodized barrel resists corrosion in humid environments, while the double-sealed carriage ensures stable load handling. Requires 5μm filtered air with ISO VG32 lubricator.
- High-speed pick-and-place systems in electronics assembly
- Palletizing robot end-effector drives
- Automated conveyor gate controls
- Precision glass panel handling equipment
- Pharmaceutical blister packaging machines
Installation guidelines:
Maintain 0.05mm/m alignment tolerance during mounting.
Apply M3×0.5 mounting screws with 2.5N·m torque.
Allow 100mm clearance behind stroke end for maintenance access.
| Property | Property Value |
|---|---|
| sku | AQK50SAAA-149X290 |
| Clamping Arm Position | Clamping Arm and Air Inlet on the Same Side |
| Port Size | PT1/4 |
| Body Mounting Dimensions | Mounting Threaded Hole M10×1.5 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Adjustment Shim | Without adjusting shim |
