Airtac AQK Dowel Pin Cylinder AQK50SAAA-157X290
2. Titanium alloy-plated pin surface for significantly enhanced wear resistance;
3. Front cover integrates a metal wiper scraper to effectively remove debris and chips;
4. Multi-directional mounting flexibility with four-sided mounting holes on the mechanism body;
5. Peripheral sensor slots on the cylinder body enable tool-free sensor attachment.
Category: Pin Clamp Cylinders | Brand: AirTAC | Series: AQK
AirTAC AQK50SAAA-157X290 Rodless Cylinder Specifications
- Model Code: AQK50SAAA-157X290
- Series: AQK-S Compact Slide Guide
- Bore size: Ø50 mm
- Stroke length: 157 mm (±0.5mm tolerance)
- Total length (L): 290 mm (including end caps)
- Operating pressure: 0.1~0.9 MPa
- Cushion type: Adjustable air cushion (both ends)
- Mounting style: Standard foot & front flange (ISO 15552 compatible)
- Piston speed: 50~800 mm/s (optimal 200~500 mm/s)
- Ambient temperature: -20℃ to 80℃
- Seal material: NBR/PU combination
- Rod material: Hardened stainless steel (SUS420)
- Body finish: Anodized aluminum alloy
- Weight: 3.7 kg (with standard fittings)
- Dimensions: 290mm(L) × 72mm(W) × 68mm(H)
- Port size: M5x0.8 (G1/8 adaptor included)
- Repeat accuracy: ±0.2mm
- Protection rating: IP65 (standard wipers)
High-precision guided rodless cylinder with integrated linear guide rails, designed for applications requiring exceptional moment resistance and positional stability. Features dual-piston seals with wear indicators and magnetic field detection slots for sensor mounting. The aluminum profile construction minimizes weight while maintaining rigidity, with hardened steel guides preventing deflection under side loads.
- High-speed pick-and-place systems in electronics assembly
- Vertical lifting mechanisms for packaging machinery
- Precision alignment stages in optical equipment
- Material transfer systems with tight space constraints
- Automated welding carriage drives
Installation guidelines:
Maintain 0.05mm/m alignment tolerance between cylinder and load path.
Use only AirTAC MCL-01 grease for relubrication (2000km service interval).
For vertical mounting, install auxiliary brake valve for fail-safe operation.
| Property | Property Value |
|---|---|
| sku | AQK50SAAA-157X290 |
| Clamping Arm Position | Clamping Arm and Air Inlet on the Same Side |
| Port Size | PT1/4 |
| Body Mounting Dimensions | Mounting Threaded Hole M10×1.5 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Adjustment Shim | Without adjusting shim |
