Airtac AQK Dowel Pin Cylinder AQK50SAAA-247X340
2. Titanium alloy-plated pin surface for significantly enhanced wear resistance;
3. Front cover integrates a metal wiper scraper to effectively remove debris and chips;
4. Multi-directional mounting flexibility with four-sided mounting holes on the mechanism body;
5. Peripheral sensor slots on the cylinder body enable tool-free sensor attachment.
Category: Pin Clamp Cylinders | Brand: AirTAC | Series: AQK
AirTAC AQK50SAAA-247X340 Pin Cylinder Specifications
- Model Code: AQK50SAAA-247X340
- Type: Double-acting pin-type cylinder (with magnetic piston)
- Bore diameter: 50 mm
- Stroke: 247 mm
- Total length: 340 mm (including end caps)
- Operating pressure: 0.05–1.0 MPa
- Piston speed: 50–800 mm/s
- Cushioning: Adjustable buffer at both ends
- Port size: G1/8 (M5×0.8 optional)
- Ambient temperature: -20℃ to 80℃
- Piston rod material: Hard chrome-plated SCM435 steel
- Cylinder tube: Aluminum alloy with hard anodized finish
- Seal material: NBR (Nitrile rubber)
- Mounting type: Front flange (standard) with 4×M6x1.0 threaded holes
- Weight: 4.8 kg ±2%
- Dimensions:
- Body diameter: 50 mm
- Extended length: 340 mm
- Mounting base: 96mm(W) × 66mm(H)
- Rod end thread: M16×1.5
- Protection rating: IP65 (dust-tight, protected against water jets)
- Compliance: ISO 6432 standard
High-precision industrial cylinder featuring a reinforced pin-style structure for enhanced lateral load capacity. The hardened piston rod and precision-ground tube ensure ≤0.5mm positioning repeatability. Integrated magnet allows position feedback with compatible sensors (inductive type recommended).
- Precision clamping in CNC machining centers
- Cartesian robot Z-axis actuation
- Die-casting machine core-pulling mechanisms
- Automotive welding fixture positioning
- High-cycle packaging machine pushers
Installation notes:
- Align mounting surface within 0.1mm/m parallelism tolerance
- Use flexible couplings for rod-end connections
- Lubricate with ISO VG32 hydraulic oil if non-lube design isn't used
- Maintain 20mm clearance around cylinder for heat dissipation
| Property | Property Value |
|---|---|
| sku | AQK50SAAA-247X340 |
| Clamping Arm Position | Clamping Arm and Air Inlet on the Same Side |
| Port Size | PT1/4 |
| Body Mounting Dimensions | Mounting Threaded Hole M10×1.5 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Adjustment Shim | Without adjusting shim |
