Airtac AQK Dowel Pin Cylinder AQK50SAAA2-159X310
2. Titanium alloy-plated pin surface for significantly enhanced wear resistance;
3. Front cover integrates a metal wiper scraper to effectively remove debris and chips;
4. Multi-directional mounting flexibility with four-sided mounting holes on the mechanism body;
5. Peripheral sensor slots on the cylinder body enable tool-free sensor attachment.
Category: Pin Clamp Cylinders | Brand: AirTAC | Series: AQK
AirTAC AQK50SAAA2-159X310 Rod Cylinder Specifications
- Model: AQK50SAAA2-159X310
- Type: Double-acting pin-type cylinder with magnetic sensor
- Bore size: 50mm
- Stroke: 159mm
- Operating pressure: 0.1–0.9 MPa
- Piston speed: 50–800 mm/s
- Port thread: G1/8 (NPT1/8 optional)
- Buffer type: Adjustable rubber cushion
- Seal material: NBR + PU combination
- Temperature range: -20℃ to 80℃
- Mounting style: Front flange (ISO 15552 standard)
- Rod end type: External thread M14×1.5
- Sensor type: Reed switch (2-wire DC)
- Weight: 2.85kg (without accessories)
- Dimensions: 310mm(L) × 62mm(W) × 62mm(H)
High-precision industrial cylinder featuring a reinforced chromium-plated rod and anti-rotation pin mechanism. The wear-resistant aluminum alloy body incorporates dual piston seals for leak-free operation. Designed for applications requiring precise linear motion and position feedback, with IP67 protection against particulate ingress.
- Precision punching machine tooling
- Automated welding fixture positioning
- Semiconductor wafer handling systems
- Die-casting mold clamping mechanisms
- High-speed packaging line pushers
Installation note:
Ensure proper alignment using the integrated guide pin slots. Lubricate with ISO VG32 hydraulic oil
during maintenance. Maximum side load capacity: 45N at full extension. Avoid continuous operation
above 70℃ without heat dissipation measures.
| Property | Property Value |
|---|---|
| sku | AQK50SAAA2-159X310 |
| Clamping Arm Position | Clamping Arm and Air Inlet on the Same Side |
| Port Size | PT1/4 |
| Body Mounting Dimensions | Mounting Threaded Hole M10×1.5 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Adjustment Shim | With Adjustment Shim 2mm |
