Airtac AQK Dowel Pin Cylinder AQK50SAAA2-177X360
2. Titanium alloy-plated pin surface for significantly enhanced wear resistance;
3. Front cover integrates a metal wiper scraper to effectively remove debris and chips;
4. Multi-directional mounting flexibility with four-sided mounting holes on the mechanism body;
5. Peripheral sensor slots on the cylinder body enable tool-free sensor attachment.
Category: Pin Clamp Cylinders | Brand: AirTAC | Series: AQK
AirTAC AQK50SAAA2-177X360 Pin Cylinder Specifications
- Model: AQK50SAAA2-177X360
- Type: Double-acting pin-type cylinder
- Bore size: 50mm
- Stroke: 360mm
- Operating pressure: 0.05–1.0 MPa
- Cushion type: Dual adjustable air cushion
- Port size: Rc1/4 (G1/4 optional)
- Mounting style: Foot-mounted (ISO 15552 standard)
- Piston rod thread: M20x1.5
- Seal material: Nitrile rubber (NBR) with wear-resistant ring
- Temperature range: -10℃ to 80℃
- Protection rating: IP65 (standard), IP67 (optional)
- Weight: ~3.8kg (excluding accessories)
- Dimensions:
- Retracted length: 537mm
- Extended length: 537mm + 360mm stroke
- Foot mounting hole spacing: 120mm x 50mm
- Rod end thread length: 25mm
High-rigidity industrial cylinder featuring precision ground stainless steel rod (Chromium Plating) and hard anodized aluminum barrel. The double-cylinder design enhances lateral load capacity by 30% compared to standard models. Integrated magnetic piston allows for position sensing compatibility. Optimal for applications requiring precise linear motion with minimal deflection.
- Automated welding fixture positioning
- Heavy-duty clamping in CNC machining centers
- Material handling systems requiring long stroke precision
- Packaging line product ejection mechanisms
- Plastic injection molding machine core pulls
Installation guidelines:
Use M10 class 8.8 mounting bolts (torque 45-50Nm). Maintain 0.5mm minimum alignment tolerance between rod and load.
Lubricate rod weekly with ISO VG32 hydraulic oil in high-cycle applications. Avoid lateral forces exceeding 220N.
- Max piston speed: 500mm/s (with cushion adjustment)
- Recommended air quality: 40μm filtration, dew point -25℃ below ambient
- Corrosion resistance: 96hr salt spray test passed
| Property | Property Value |
|---|---|
| sku | AQK50SAAA2-177X360 |
| Clamping Arm Position | Clamping Arm and Air Inlet on the Same Side |
| Port Size | PT1/4 |
| Body Mounting Dimensions | Mounting Threaded Hole M10×1.5 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Adjustment Shim | With Adjustment Shim 2mm |
