Airtac AQK Dowel Pin Cylinder AQK50SAAA2-178X360
$351.25
Regular price
$358.75
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
AQK50SAAA2-178X360
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
Product Description of AirTAC AQK Pin Clamp Cylinder:
1. Compliant with JIS industrial standards;
2. Titanium alloy-plated pin surface for significantly enhanced wear resistance;
3. Front cover integrates a metal wiper scraper to effectively remove debris and chips;
4. Multi-directional mounting flexibility with four-sided mounting holes on the mechanism body;
5. Peripheral sensor slots on the cylinder body enable tool-free sensor attachment.
Category: Pin Clamp Cylinders | Brand: AirTAC | Series: AQK
Installation guidelines:
Maximum permissible lateral load 220N. Use flexible couplings when connecting to guided systems.
For vertical mounting, install rod end downward to prevent seal wear from condensed water.
2. Titanium alloy-plated pin surface for significantly enhanced wear resistance;
3. Front cover integrates a metal wiper scraper to effectively remove debris and chips;
4. Multi-directional mounting flexibility with four-sided mounting holes on the mechanism body;
5. Peripheral sensor slots on the cylinder body enable tool-free sensor attachment.
Category: Pin Clamp Cylinders | Brand: AirTAC | Series: AQK
AirTAC AQK50SAAA2-178X360 Rodless Cylinder Specifications
- Series: AQK-S Standard Type
- Bore size: Ø50 mm
- Stroke: 178 mm
- Operating pressure: 0.1-0.9 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable pneumatic cushion (both ends)
- Port size: 1/4" NPT (G1/8 optional)
- Piston rod thread: M12×1.25
- Mounting type: Basic type (no flange)
- Material:
- Cylinder tube: Aluminum alloy hard oxidation
- Piston rod: Stainless steel (SUS304)
- Seals: NBR + PU combination
- Weight: 5.8 kg (±2%)
- Dimensions:
- Total length: 360 mm
- Mounting hole spacing: 170 mm
- Height (including rod): 125 mm
- Width: 50 mm
- Protection class: IP65 (standard wiper included)
- Lubrication: Pre-lubricated (Use ISO VG32 turbine oil if re-lubrication needed)
High-precision rodless cylinder with T-slot design for direct load mounting. Features dual piston seals for leak-free operation and magnetic field sensor compatibility (sensor not included). The anodized surface treatment provides enhanced corrosion resistance in humid environments.
Industrial Applications:
- Palletizing robot end-effector drives
- CNC machine tool fixture positioning
- Automotive welding line transfer systems
- Pharmaceutical packaging linear actuators
- Electronics assembly press-fit mechanisms
Installation guidelines:
Maximum permissible lateral load 220N. Use flexible couplings when connecting to guided systems.
For vertical mounting, install rod end downward to prevent seal wear from condensed water.
Cycle Life:
5,000 km travel distance or 10 million cycles (whichever comes first) under standard operating conditions.
Recommend replacing cushion seals every 2 million cycles in high-speed applications (>1 m/s).
| Property | Property Value |
|---|---|
| sku | AQK50SAAA2-178X360 |
| Clamping Arm Position | Clamping Arm and Air Inlet on the Same Side |
| Port Size | PT1/4 |
| Body Mounting Dimensions | Mounting Threaded Hole M10×1.5 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Adjustment Shim | With Adjustment Shim 2mm |
