Airtac AQK Dowel Pin Cylinder AQK50SAAA2-197X360
2. Titanium alloy-plated pin surface for significantly enhanced wear resistance;
3. Front cover integrates a metal wiper scraper to effectively remove debris and chips;
4. Multi-directional mounting flexibility with four-sided mounting holes on the mechanism body;
5. Peripheral sensor slots on the cylinder body enable tool-free sensor attachment.
Category: Pin Clamp Cylinders | Brand: AirTAC | Series: AQK
AirTAC AQK50SAAA2-197X360 Rodless Cylinder Specifications
- Model: AQK50SAAA2-197X360
- Series: AQK-S compact slide guide series
- Bore size: 50mm (ISO 6432 standard)
- Stroke: 197mm (adjustable cushioning range ±5mm)
- Operating pressure: 0.1–0.9 MPa
- Medium temperature: -20℃ to 80℃ (dry air required)
- Cushioning type: External adjustable rubber + air cushion
- Port size: M5x0.8 (G1/8 optional)
- Piston material: Aluminum alloy AL6061-T6
- Rod material: Chrome-plated carbon steel S45C
- Seal material: NBR (nitrile rubber)
- Repeat positioning accuracy: ±0.2mm
- Max speed: 500-700 mm/s (lubricated)
- Weight: 2.8 kg (with standard accessories)
- Dimensions: 360mm(L) × 68mm(W) × 62mm(H)
- Protection rating: IP54 (standard), IP67 optional
- Mounting type: Standard side-mount with 4x M6 threaded holes
High-precision rodless cylinder with integrated linear guide rails, designed for heavy-duty applications requiring lateral stability. Features dual-slot piston design for balanced force distribution and reduced bearing wear. The aluminum extrusion body provides corrosion resistance in humid environments. Requires ISO 8573-1 class 3 or cleaner compressed air.
- Automated material handling systems
- Palletizing robot end-effectors
- CNC machine tool clamping mechanisms
- Lithium battery production line transfers
- Pharmaceutical blister packaging machines
Installation note:
Ensure guide rail alignment within 0.1mm/m parallelism tolerance.
Lubricate through air port with ISO VG32 turbine oil monthly.
Avoid side load exceeding 150N during operation.
| Property | Property Value |
|---|---|
| sku | AQK50SAAA2-197X360 |
| Clamping Arm Position | Clamping Arm and Air Inlet on the Same Side |
| Port Size | PT1/4 |
| Body Mounting Dimensions | Mounting Threaded Hole M10×1.5 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Adjustment Shim | With Adjustment Shim 2mm |
