Airtac AQK Dowel Pin Cylinder AQK50SAAA2-199X360
2. Titanium alloy-plated pin surface for significantly enhanced wear resistance;
3. Front cover integrates a metal wiper scraper to effectively remove debris and chips;
4. Multi-directional mounting flexibility with four-sided mounting holes on the mechanism body;
5. Peripheral sensor slots on the cylinder body enable tool-free sensor attachment.
Category: Pin Clamp Cylinders | Brand: AirTAC | Series: AQK
AirTAC AQK50SAAA2-199X360 Rodless Cylinder Specifications
- Model: AQK50SAAA2-199X360
- Type: ISO 15552 compliant rodless cylinder (Double-acting)
- Bore size: Ø50 mm
- Stroke length: 360 mm (±0.5mm tolerance)
- Operating pressure: 0.1–0.9 MPa
- Cushioning type: Adjustable pneumatic cushion at both ends
- Mounting style: Standard foot mounting (MF1)
- Port size: PT1/4 (G1/4 optional)
- Temperature range: -20℃ to 80℃
- Piston rod material: Stainless steel (SUS304)
- Seal material: NBR (Nitrile rubber)
- Protection rating: IP65 (Dust-tight & water jet resistant)
- Weight: 4.8 kg (with standard fittings)
- Dimensions: 199mm (Retracted length) × 68mm (Width) × 68mm (Height)
- Max theoretical force: 1,570N @ 0.63MPa
- Piston speed: 50–700 mm/s (optimal range)
High-precision rodless cylinder with integrated T-slot carriage for direct load mounting. Features chrome-plated aluminum barrel with wear-resistant guide mechanism, designed for smooth linear motion in automation systems. Includes built-in magnetic sensor slots (NPN/PNP compatible) for position feedback.
- High-speed packaging line pusher mechanisms
- Automotive assembly line part transfer systems
- Palletizing robot end-effector actuators
- CNC machine tool door operators
- Electronic component testing equipment
Installation note:
Ensure proper alignment of guide rails within 0.2mm/m tolerance. Lubricate with ISO VG32 hydraulic oil
during initial setup. Avoid side load exceeding 30% of maximum thrust capacity.
- Replace seals every 5,000 km cumulative travel or 3 years
- Inspect carriage bolts torque (12 N·m) quarterly
- Use 40μm filtered compressed air with dew point -20℃ below ambient
| Property | Property Value |
|---|---|
| sku | AQK50SAAA2-199X360 |
| Clamping Arm Position | Clamping Arm and Air Inlet on the Same Side |
| Port Size | PT1/4 |
| Body Mounting Dimensions | Mounting Threaded Hole M10×1.5 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Adjustment Shim | With Adjustment Shim 2mm |
