Airtac AQK Dowel Pin Cylinder AQK50SAAA2-247X360
2. Titanium alloy-plated pin surface for significantly enhanced wear resistance;
3. Front cover integrates a metal wiper scraper to effectively remove debris and chips;
4. Multi-directional mounting flexibility with four-sided mounting holes on the mechanism body;
5. Peripheral sensor slots on the cylinder body enable tool-free sensor attachment.
Category: Pin Clamp Cylinders | Brand: AirTAC | Series: AQK
AirTAC AQK Series Rodless Cylinder AQK50SAAA2-247X360 Technical Details
- Model Code Breakdown:
AQK50-S-AA-A2-247-X360
- AQK: Rodless cylinder series
- 50: Bore size Ø50mm
- S: Standard type (non-guided)
- AA: Dual piston design
- A2: Cushion type (adjustable air cushion both ends)
- 247: Stroke length 247mm
- X360: Special coating option (X coating for corrosion resistance)
- Operating pressure: 0.05–1.0 MPa
- Max thrust: 1960N @ 0.63MPa
- Ambient temperature: -10℃ to 70℃ (no freeze)
- Piston speed: 50–800 mm/s
- Mounting type: Standard foot mount (M8x1.25 mounting holes)
- Port size: G1/8 (NPT1/8 optional)
- Seal material: Polyurethane (NBR seals available on request)
- Body material: Anodized aluminum alloy (X coating adds 5μm protective layer)
- Weight: 5.8kg ±2% (with mounting brackets)
- Dimensions:
- Total length: 618mm (247mm stroke + 371mm base length)
- Body height: 82mm
- Width: 60mm
- Mounting hole spacing: 40mm x 40mm grid
- ISO certification: Complies with ISO 6431 standard
- Protection class: IP54 (standard), upgradable to IP67
High-precision rodless cylinder with X-coat anti-corrosion treatment, designed for heavy-load linear motion in harsh environments. Features dual piston structure for enhanced stability and 0.01mm repeat positioning accuracy. Integrated shock absorbers prevent end-position vibration. Compatible with magnetic sensors for position feedback.
- Automated palletizing systems requiring long stroke precision
- Plastic injection molding machine core-pulling mechanisms
- CNC machine tool chip conveyors
- Food processing lines (when using food-grade grease)
- Electroplating line material handling (benefits from X-coat protection)
Operation notes:
Requires ISO VG32 hydraulic oil mist lubrication (0.3-0.6cc/min).
Avoid side loads exceeding 200N. For vertical installations,
always use air pressure holding circuit. Maximum allowable
lateral misalignment: ±0.5mm.
- Relubrication: Every 500km of travel or 6 months
- Bearing inspection: Every 1,000,000 cycles
- X-coat reapplication: 5 years (salt spray environments)
| Property | Property Value |
|---|---|
| sku | AQK50SAAA2-247X360 |
| Clamping Arm Position | Clamping Arm and Air Inlet on the Same Side |
| Port Size | PT1/4 |
| Body Mounting Dimensions | Mounting Threaded Hole M10×1.5 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Adjustment Shim | With Adjustment Shim 2mm |
