Airtac AQK Dowel Pin Cylinder AQK50SAAA2-248X360
2. Titanium alloy-plated pin surface for significantly enhanced wear resistance;
3. Front cover integrates a metal wiper scraper to effectively remove debris and chips;
4. Multi-directional mounting flexibility with four-sided mounting holes on the mechanism body;
5. Peripheral sensor slots on the cylinder body enable tool-free sensor attachment.
Category: Pin Clamp Cylinders | Brand: AirTAC | Series: AQK
AirTAC AQK50SAAA2-248X360 Rodless Cylinder Specifications
- Model: AQK50SAAA2-248X360
- Type: Compact guide rod cylinder (ISO 15552 standard)
- Bore size: Ø50 mm
- Stroke: 360 mm (adjustable cushion)
- Operating pressure: 0.05–1.0 MPa
- Max thrust: 1960N at 0.7MPa
- Action type: Double-acting
- Mounting style: Basic type with axial mounting holes
- Seal material: NBR/PU hybrid seals
- Temperature range: -20℃ to 80℃
- Piston speed: 50–700 mm/s
- Weight: 5.8 kg (with standard fittings)
- Dimensions: 248mm (body length) × 85mm (W) × 50mm (H)
- Cushion type: Adjustable rubber buffers at both ends
- Rod end type: Female thread M14×1.5
- Protection rating: IP54 (standard), IP67 optional
High-precision rodless cylinder with integrated linear guide rails, engineered for precision positioning in automated systems. Features wear-resistant chromium-plated piston rod and anti-rotation mechanism. Requires filtered air (5-50μm) with ISO VG32 lubricant recommended for optimal performance.
- PCB handling robots in electronics manufacturing
- Glass panel transfer systems
- Automated welding equipment positioning
- Pharmaceutical blister packaging machines
- Precision stamping press feeders
Installation guidelines:
Mount on precision-machined surface (flatness ≤0.1mm/m). Use M6×12 mounting
screws with 0.8–1.2Nm torque. Align guide rails within 0.05mm parallel tolerance.
Lubricate every 2,000km of travel or 6 months operation.
- ±0.05mm repeat positioning accuracy
- 3,000km minimum service life (under standard load)
- Silent operation (<65dB at 0.5m distance)
- Corrosion-resistant anodized aluminum body
| Property | Property Value |
|---|---|
| sku | AQK50SAAA2-248X360 |
| Clamping Arm Position | Clamping Arm and Air Inlet on the Same Side |
| Port Size | PT1/4 |
| Body Mounting Dimensions | Mounting Threaded Hole M10×1.5 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Adjustment Shim | With Adjustment Shim 2mm |
