Airtac AQK Dowel Pin Cylinder AQK50SAAA2-249X360
2. Titanium alloy-plated pin surface for significantly enhanced wear resistance;
3. Front cover integrates a metal wiper scraper to effectively remove debris and chips;
4. Multi-directional mounting flexibility with four-sided mounting holes on the mechanism body;
5. Peripheral sensor slots on the cylinder body enable tool-free sensor attachment.
Category: Pin Clamp Cylinders | Brand: AirTAC | Series: AQK
AirTAC AQK Series Pin Cylinder AQK50SAAA2-249X360 Full Specifications
- Model Code: AQK50SAAA2-249X360
- Series: AQK (Double Rod Heavy Duty Type)
- Bore Size: Ø50 mm
- Stroke: 360 mm (Customizable up to 500mm)
- Operating Pressure: 0.05-1.0 MPa
- Cushioning: Adjustable Air Cushion (Both Ends)
- Mounting Type: SA Series - Front Flange with Through Hole Mounting
- Port Size: M5x0.8 (Standard) / NPT1/8 Optional
- Piston Rod Diameter: Ø16mm x 2 (Double Rod)
- Seal Material: High-grade NBR + Special Polyurethane
- Temperature Range: -20℃ to 80℃ (Dry Air Required Below 0℃)
- Protection Rating: IP65 (Dust Proof & Water Jet Resistance)
- Weight: 6.8 kg (Dry Weight, Without Accessories)
- Dimensions:
- Length: 249mm (Basic Length L1)
- Width: 84mm (Flange Mounting Base Width)
- Height: 70mm (Cylinder Body Height)
- Total Extended Length: 249 + 360 = 609mm
High-precision double rod cylinder engineered for heavy-load linear motion applications. Features chromium-plated piston rods with dual wiper seals for contamination resistance. The through-hole flange design enables rigid mounting in automated systems requiring precise alignment. Optional magnetic piston version (Add "-M" suffix) available for position feedback.
- Automated welding fixture positioning systems
- Palletizing robot end-effector drives
- CNC machine tool clamping mechanisms
- Automotive assembly line transfer units
- Glass cutting equipment pressure control
Maintenance Tip:
Lubricate with ISO VG32 hydraulic oil mist lubrication (1 drop per cycle).
Avoid side load exceeding 30N·m. For vertical mounting, use counterbalance valves.
- Max Speed: 500 mm/s (With cushion adjustment)
- Repeat Positioning Accuracy: ±0.2mm
- Maximum Lateral Load: 980N at mid-stroke
- Endurance: 5,000km (Under standard load conditions)
| Property | Property Value |
|---|---|
| sku | AQK50SAAA2-249X360 |
| Clamping Arm Position | Clamping Arm and Air Inlet on the Same Side |
| Port Size | PT1/4 |
| Body Mounting Dimensions | Mounting Threaded Hole M10×1.5 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Adjustment Shim | With Adjustment Shim 2mm |
