AirTAC AR150-01 AR1500/2000 Pressure Regulator (AR15001)
1. Features compact and lightweight design for simplified installation and operation;
2. Integrated press-in self-locking mechanism prevents unintended pressure setting changes due to external disturbances;
3. Optional low-pressure variant available (maximum adjustable pressure 0.4MPa) in addition to standard configuration.
Category: Pressure Regulator | Brand: AIRTAC | Series: AR1500/2000
AirTAC AR1500/2000 Series Pressure Regulator AR15001 Technical Details
- Model: AR15001 (AR1500/2000 series)
- Type: Precision air pressure regulator with gauge
- Port size: Rc1/4 (BSPP) or NPT1/4 optional
- Operating pressure range: 0.05–0.85 MPa
- Maximum pressure: 1.0 MPa
- Flow capacity: 3,500 Nl/min (ANR)
- Adjustment knob rotation: 270°±5°
- Locking mechanism: Push-pull locking collar
- Body material: Die-cast aluminum alloy (anodized)
- Seal material: HNBR (Hydrogenated Nitrile)
- Temperature range: -5℃ to 60℃ (no freeze)
- Weight: 480g ±5% (without accessories)
- Dimensions: 118mm(H) × 50mm(W) × 50mm(D)
- Gauge range: 0–1.0 MPa (standard), optional 0.1–1.6 MPa
- Pressure gauge accuracy: Class 2.5
- Mounting orientation: Any (vertical recommended)
High-sensitivity pressure regulator featuring dual-chamber design for stable output under fluctuating input pressures. The integrated damped gauge minimizes needle vibration, while the ergonomic ribbed knob allows precise adjustments even with gloves. Includes built-in filter screen (40μm) and automatic pressure relief safety mechanism.
- Pneumatic actuator pressure stabilization in assembly lines
- Air tool pressure management in automotive workshops
- Packaging machine air circuit pressure control
- Laboratory pneumatic instrument calibration systems
- Semiconductor manufacturing cleanroom environments
Installation guidelines:
Install downstream of filter/lubricator (FRL) units. For vertical mounting,
position gauge at 30°~90° viewing angle. Perform initial "burping" by
rotating knob full open-closed 3x before calibration. Replace desiccant
cartridge every 2,000 operational hours.
| Property | Property Value |
|---|---|
| sku | AR15001 |
| Port Size | PT1/8 |
