Airtac ASQ Series Single Acting Slim Cylinder ASQ16X10S
2. Features C-shaped retaining rings for barrel-end cap fixation and riveted piston-rod connection, ensuring structural compactness and reliability;
3. Honed inner diameter barrel surface enhances wear resistance and operational longevity;
4. Extended guide distance on front cap optimizes alignment stability;
5. Space-saving design minimizes installation footprint;
6. Integrated sensor grooves along barrel periphery facilitate easy sensor mounting;
7. Versatile mounting accessories available for multiple configuration options;
Category: Compact Cylinder | Brand: AIRTAC | Series: ASQ Single-Acting Cylinder
AirTAC ASQ16X10S Single-Acting Compact Cylinder Specifications
- Model: ASQ16X10S
- Type: Single-acting (spring return)
- Bore size: 16mm
- Stroke: 10mm
- Operating pressure: 0.05–0.9 MPa
- Operating medium: Dry air (lubricated or non-lubricated)
- Port size: M5x0.8 (standard) / NPT1/8 (optional)
- Cushioning: Elastic buffer
- Temperature range: -20℃ to 80℃
- Cylinder material: Aluminum alloy barrel, stainless steel piston rod
- Seal material: NBR (Nitrile rubber)
- Mounting type: Basic type (no built-in mounting)
- Weight: 0.15kg ±5%
- Dimensions (L×W×H):
- Minimum retracted length: 53mm
- Maximum extended length: 63mm
- Body width: 20mm
- Mounting hole spacing: 25mm (longitudinal)
Ultra-slim profile pneumatic cylinder optimized for space-constrained automation systems. Features precision honed tubing for smooth operation and anti-rotation piston design. The chrome-plated piston rod provides enhanced corrosion resistance, while the modular structure allows easy maintenance. Requires 5μm filtered air for optimal performance.
- Semiconductor wafer handling robots
- Medical device actuation (IV bag compressors, ventilator valves)
- Precision clamping in CNC tool changers
- Packaging machine flap control
- Automated test equipment positioners
Installation guidance:
Ensure piston rod alignment within 0.5° angular tolerance. For vertical mounting,
use spring-side port as default exhaust. Lubricate every 3M cycles with ISO VG32
turbine oil if using non-lubricated air supply.
| Property | Property Value |
|---|---|
| sku | ASQ16X10S |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | S-Magnetic |
| Bore Diameter | 16mm |
| Stroke | <10mm> |
