Airtac ASQ Series Single Acting Slim Cylinder ASQ16X10SB
2. Features C-shaped retaining rings for barrel-end cap fixation and riveted piston-rod connection, ensuring structural compactness and reliability;
3. Honed inner diameter barrel surface enhances wear resistance and operational longevity;
4. Extended guide distance on front cap optimizes alignment stability;
5. Space-saving design minimizes installation footprint;
6. Integrated sensor grooves along barrel periphery facilitate easy sensor mounting;
7. Versatile mounting accessories available for multiple configuration options;
Category: Compact Cylinder | Brand: AIRTAC | Series: ASQ Single-Acting Cylinder
AirTAC ASQ16X10SB Single-Acting Compact Cylinder Specifications
- Model: ASQ16X10SB
- Type: Single-acting spring return (compact series)
- Bore size: 16mm
- Stroke: 10mm (±1mm tolerance)
- Port size: M5x0.8 (dual ports)
- Operating pressure: 0.15–0.8 MPa
- Piston speed: 50–800 mm/s
- Operating temperature: -20℃ to 80℃
- Cushioning: Rubber pad buffer
- Mounting types: Front flange (MF1), rear flange (MF2), or foot mount (MP2)
- Material: Aluminum alloy barrel/piston rod, NBR seals
- Weight: 0.12kg (bare cylinder), 0.15kg (with accessories)
- Dimensions: 60mm(L) × 25mm(W) × 25mm(H) (excluding rod extension)
- Rod thread: M4x0.7 external thread
- ISO standard: Compliant with ISO 6432 (8mm mounting hole spacing)
Ultra-slim profile cylinder optimized for space-constrained automation systems. Features anti-rotation piston rod design and dual-port configuration for flexible piping. The chrome-plated piston rod ensures corrosion resistance in humid environments. Requires 40μm filtered lubricated air (ISO 8573-1 class 4).
- PCB handling robots in electronics assembly
- Clamping mechanisms in CNC tool changers
- Valve actuation in beverage dispensing systems
- Medical bed height adjustment mechanisms
- Compact sliding doors in cleanroom environments
Installation note:
Maintain 0.5mm minimum clearance between rod end and load during alignment.
For vertical mounting, use speed controller to prevent free-fall. Lubricate every
500km of cumulative stroke travel.
| Property | Property Value |
|---|---|
| sku | ASQ16X10SB |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Bore Diameter | 16mm |
| Stroke | <10mm> |
