Airtac ASQ Series Single Acting Slim Cylinder ASQ16X15
2. Features C-shaped retaining rings for barrel-end cap fixation and riveted piston-rod connection, ensuring structural compactness and reliability;
3. Honed inner diameter barrel surface enhances wear resistance and operational longevity;
4. Extended guide distance on front cap optimizes alignment stability;
5. Space-saving design minimizes installation footprint;
6. Integrated sensor grooves along barrel periphery facilitate easy sensor mounting;
7. Versatile mounting accessories available for multiple configuration options;
Category: Compact Cylinder | Brand: AIRTAC | Series: ASQ Single-Acting Cylinder
AirTAC ASQ16X15 Single-Acting Compact Cylinder Specifications
- Model: ASQ16X15
- Type: Single-acting (spring return)
- Bore size: 16mm
- Stroke: 15mm
- Operating pressure: 0.15-0.8 MPa
- Temperature range: -20℃ to 80℃
- Cushion type: Adjustable rubber cushion
- Port size: M5x0.8 (G1/8 optional)
- Piston speed: 50-700 mm/s
- Seal material: NBR/PU (nitrile/polyurethane)
- Mounting types: Basic/Foot-mounted/Flange
- Weight: 0.24kg ±2%
- Dimensions (L×W×H): 70mm × 20mm × 20mm (excluding rod)
- Rod thread: M6x1.0
- Max theoretical thrust: 15.4N @0.5MPa
- Protection class: IP65 (dust-proof & water jet resistant)
Ultra-slim profile cylinder optimized for space-constrained automation systems. Features corrosion-resistant aluminum alloy construction with hard-anodized piston rod (Rockwell HRC 35-40). The spring-return mechanism ensures fail-safe retraction during pressure loss. Compatible with both non-lubricated and lubricated air systems (ISO 8573-1 class 3).
- PCB handling robots in electronics manufacturing
- Medical device actuation mechanisms
- Automatic door locking systems
- Textile machinery thread control
- Precision dispensing equipment
- Laboratory sample positioning stages
Installation note:
Maintain 0.5-1mm clearance between rod end and load during alignment.
For vertical mounting, use in downward thrust configuration only.
Lubricate with ISO VG32 hydraulic oil if operating below -10℃.
| Property | Property Value |
|---|---|
| sku | ASQ16X15 |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 16mm |
| Stroke | <15mm> |
