Airtac ASQ Series Single Acting Slim Cylinder ASQ16X15B
2. Features C-shaped retaining rings for barrel-end cap fixation and riveted piston-rod connection, ensuring structural compactness and reliability;
3. Honed inner diameter barrel surface enhances wear resistance and operational longevity;
4. Extended guide distance on front cap optimizes alignment stability;
5. Space-saving design minimizes installation footprint;
6. Integrated sensor grooves along barrel periphery facilitate easy sensor mounting;
7. Versatile mounting accessories available for multiple configuration options;
Category: Compact Cylinder | Brand: AIRTAC | Series: ASQ Single-Acting Cylinder
AirTAC ASQ16X15B Single-Acting Compact Cylinder Specifications
- Model: ASQ16X15B
- Type: Single-acting (spring return)
- Bore size: 16mm
- Stroke: 15mm
- Operating pressure: 0.05–0.8 MPa
- Port size: M5x0.8 (standard) / NPT1/8 (optional)
- Piston speed: 50–800 mm/s
- Buffer type: Rubber cushion (adjustable end caps)
- Seal material: NBR (nitrile) with polyurethane wear bands
- Temperature range: -20℃ to 80℃
- Weight: 0.12kg ±5%
- Dimensions: 54mm(L) × 34mm(W) × 34mm(H)
- Mounting: Standard ISO 6432 mounting slots
- Rod end: Female M5 thread (ISO 1179)
- Protection rating: IP67 (dust/water resistant)
Ultra-slim profile cylinder optimized for space-constrained automation systems. Features precision honed aluminum tube and chrome-plated piston rod for smooth operation. Spring return mechanism provides reliable retraction force up to 3.2N (at 0.5MPa). Compatible with ISO 6432 mounting accessories.
- PCB handling robots in electronics assembly
- Medical device clamping mechanisms
- Packaging machine gate actuators
- Semiconductor wafer positioning systems
- Cleanroom automation equipment
Installation note:
Lubricate rod with silicone grease (Molykote 33M) before initial use.
For vertical mounting, ensure spring chamber faces downward to prevent
condensate accumulation. Maintain 2mm minimum clearance around cylinder body.
| Property | Property Value |
|---|---|
| sku | ASQ16X15B |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | External Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 16mm |
| Stroke | <15mm> |
