Airtac ASQ Series Single Acting Slim Cylinder ASQ16X20
2. Features C-shaped retaining rings for barrel-end cap fixation and riveted piston-rod connection, ensuring structural compactness and reliability;
3. Honed inner diameter barrel surface enhances wear resistance and operational longevity;
4. Extended guide distance on front cap optimizes alignment stability;
5. Space-saving design minimizes installation footprint;
6. Integrated sensor grooves along barrel periphery facilitate easy sensor mounting;
7. Versatile mounting accessories available for multiple configuration options;
Category: Compact Cylinder | Brand: AIRTAC | Series: ASQ Single-Acting Cylinder
AirTAC ASQ16X20 Single-Acting Compact Cylinder Specifications
- Model: ASQ16X20
- Type: Single-acting spring return (push type)
- Bore size: 16mm
- Stroke: 20mm
- Operating pressure: 0.15–0.8 MPa
- Port size: M5x0.8 (1/8" NPT optional)
- Cushioning: Adjustable rubber buffer
- Piston speed: 50–700 mm/s
- Ambient temperature: -20℃ to 80℃
- Material:
- Cylinder tube: Aluminum alloy (hard anodized)
- Piston rod: Stainless steel (SUS304)
- Seals: NBR (nitrile rubber)
- Weight: 0.15kg (excluding accessories)
- Dimensions:
- Total length (retracted): 53mm
- Width: 40mm
- Height: 35mm
- Mounting hole spacing: 25mm (standard)
- Protection class: IP65 (dust-tight & water jet resistant)
- Lubrication: Pre-lubricated (use ISO VG32 turbine oil if maintenance required)
Ultra-slim profile cylinder optimized for space-constrained automation systems. Features a dual-guide rod design for enhanced lateral load capacity (max 5N lateral force at full extension). The aluminum body with black anodized finish provides corrosion resistance in humid environments. Includes magnetic piston for position sensing compatibility.
- PCB handling robots in electronics assembly
- Medical device actuation mechanisms
- Compact clamping fixtures for CNC machines
- Automatic door locking systems
- Photovoltaic panel positioning systems
Installation guidelines:
Maintain 0.5mm minimum clearance between magnetic sensor and cylinder body.
For vertical mounting, use spring-side port as exhaust. Lubricate every 3 million cycles
in normal operation. Avoid side load exceeding 30% of maximum thrust capacity.
Minimum operating pressure: 0.05MPa (with reduced thrust output)
Air consumption per cycle: 0.16L (ANR)
| Property | Property Value |
|---|---|
| sku | ASQ16X20 |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 16mm |
| Stroke | <20mm> |
