Airtac ATE Single Acting Guided Compact Cylinder ATE100X10S
2. Threaded connection between cylinder body and end covers ensures structural integrity and serviceability;
3. Precision-machined bore with hard anodized surface treatment delivers exceptional wear resistance and extended service life;
4. Asymmetric bidirectional piston sealing design with integrated oil reservoirs optimizes compact dimensions while maintaining lubrication efficiency;
5. Space-saving profile achieves 50% reduction in installation footprint compared to ISO 15552 standard cylinders of equivalent bore size;
6. Triple-side sensor slots facilitate straightforward proximity switch integration;
7. Integrated shock-absorbing cushions effectively mitigate residual kinetic energy from high-speed and rotational applications;
8. Versatile mounting accessories available for multiple configurations.
Category: Compact Cylinders | Brand: AirTAC | Series: ATE Single-Acting Compact Cylinder
AirTAC ATE100X10S Single-Action Spring-Return Compact Cylinder Specifications
- Model: ATE100X10S
- Type: Single-acting (spring return) compact cylinder
- Bore size: 100mm
- Stroke: 10mm
- Operating pressure: 0.05–0.9 MPa
- Port size: G1/8 (ISO228/1 standard)
- Cushioning: Fixed rubber buffer
- Piston material: Aluminum alloy with hard anodization
- Rod material: Chrome-plated steel
- Seal material: NBR (nitrile rubber)
- Ambient temperature: -20℃ to 80℃
- Weight: 1.45kg ±3%
- Dimensions: 140mm(L) × 108mm(W) × 108mm(H)
- Mounting style: Front flange (MF1) with optional rear pivot
- Protection rating: IP65 (standard wiper design)
High-precision compact cylinder featuring space-saving design with integrated mounting grooves. The chrome-plated piston rod provides corrosion resistance in humid environments. Requires 5-40μm filtered air with 1-2 drops of ISO VG32 oil per m³. Spring return mechanism ensures fail-safe retraction during pressure loss.
- Electronics assembly line clamping fixtures
- Food processing machine ejection mechanisms
- Plastic injection molding machine core-pulling
- Automated warehouse vertical lift positioning
- Pharmaceutical blister packing press systems
Installation note:
Maintain ≤0.5mm alignment tolerance during mounting. Lubricate rod every 500km stroke
using ISO HM hydraulic oil. Avoid lateral loads exceeding 30N to prevent rod deflection.
| Property | Property Value |
|---|---|
| sku | ATE100X10S |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | G1/8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | <10mm> |
