Airtac ATE Single Acting Guided Compact Cylinder ATE100X20B
2. Threaded connection between cylinder body and end covers ensures structural integrity and serviceability;
3. Precision-machined bore with hard anodized surface treatment delivers exceptional wear resistance and extended service life;
4. Asymmetric bidirectional piston sealing design with integrated oil reservoirs optimizes compact dimensions while maintaining lubrication efficiency;
5. Space-saving profile achieves 50% reduction in installation footprint compared to ISO 15552 standard cylinders of equivalent bore size;
6. Triple-side sensor slots facilitate straightforward proximity switch integration;
7. Integrated shock-absorbing cushions effectively mitigate residual kinetic energy from high-speed and rotational applications;
8. Versatile mounting accessories available for multiple configurations.
Category: Compact Cylinders | Brand: AirTAC | Series: ATE Single-Acting Compact Cylinder
AirTAC ATE100X20B Single-Acting Compact Cylinder Specifications
- Model: ATE100X20B
- Type: Single-acting spring return (push type)
- Bore size: 10mm (customizable up to 16mm)
- Stroke: 20mm (±1mm tolerance)
- Operation: Air to extend, spring to retract
- Operating pressure: 0.05–0.9 MPa
- Port size: M5 (standard) with G1/8 adapter optional
- Cushioning: Adjustable rubber buffer
- Seal material: NBR + PU hybrid seals
- Temperature range: -10℃ to 80℃
- Mounting: ISO 6432 standard (2x M3 threaded holes)
- Protection rating: IP57 (dust/water resistant)
- Material: Anodized aluminum body, CR12MoV piston rod
- Weight: 0.65kg (without accessories)
- Dimensions: 100mm(L) × 20mm(W) × 20mm(H) (extended state)
A space-saving pneumatic actuator featuring precision-ground inner bore and wear-resistant rod coating. The chrome-plated piston rod (Rockwell HRC 35-40) ensures smooth operation across 2 million cycles. Requires 5-40μm filtered air with ISO VG32 lubricant (optional oil-free operation). Includes built-in magnetic sensor slot for position feedback.
- PCB handling robots in electronics assembly
- Clamping mechanisms in CNC tool changers
- Valve actuation in laboratory analyzers
- Precision dosing systems in pharmaceutical packaging
- Automated door locks in cleanroom environments
Installation tip:
For vertical mounting, maintain ≤0.5mm alignment tolerance. Use Loctite 243
on mounting screws and allow 2mm thermal expansion gap in high-cycle (>10Hz) applications.
| Property | Property Value |
|---|---|
| sku | ATE100X20B |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | G1/8 |
| Piston Rod Thread Type | External Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 100mm |
| Stroke | <20mm> |
