Airtac ATE Single Acting Guided Compact Cylinder ATE100X25B
$118.61
Regular price
$126.11
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
ATE100X25B
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Compliant with ISO 21287 standard for enhanced cross-brand installation compatibility;
2. Threaded connection between cylinder body and end covers ensures structural integrity and serviceability;
3. Precision-machined bore with hard anodized surface treatment delivers exceptional wear resistance and extended service life;
4. Asymmetric bidirectional piston sealing design with integrated oil reservoirs optimizes compact dimensions while maintaining lubrication efficiency;
5. Space-saving profile achieves 50% reduction in installation footprint compared to ISO 15552 standard cylinders of equivalent bore size;
6. Triple-side sensor slots facilitate straightforward proximity switch integration;
7. Integrated shock-absorbing cushions effectively mitigate residual kinetic energy from high-speed and rotational applications;
8. Versatile mounting accessories available for multiple configurations.
Category: Compact Cylinders | Brand: AirTAC | Series: ATE Single-Acting Compact Cylinder
Installation note:
Requires minimum 5μm filtered air supply. For horizontal mounting,
reduce max speed to 70% of rated capacity. Lubricate through air
port using ISO VG32 hydraulic oil monthly. Maintain 15mm clearance
behind cylinder for rod extension.
2. Threaded connection between cylinder body and end covers ensures structural integrity and serviceability;
3. Precision-machined bore with hard anodized surface treatment delivers exceptional wear resistance and extended service life;
4. Asymmetric bidirectional piston sealing design with integrated oil reservoirs optimizes compact dimensions while maintaining lubrication efficiency;
5. Space-saving profile achieves 50% reduction in installation footprint compared to ISO 15552 standard cylinders of equivalent bore size;
6. Triple-side sensor slots facilitate straightforward proximity switch integration;
7. Integrated shock-absorbing cushions effectively mitigate residual kinetic energy from high-speed and rotational applications;
8. Versatile mounting accessories available for multiple configurations.
Category: Compact Cylinders | Brand: AirTAC | Series: ATE Single-Acting Compact Cylinder
AirTAC ATE100X25B Single-Acting Compact Guided Cylinder Specifications
- Model: ATE100X25B
- Type: Single-acting spring return (piston rod introduction type)
- Bore size: Ø100mm
- Stroke: 25mm (±1.5mm tolerance)
- Operating pressure: 0.1–0.9 MPa
- Port thread: PT1/4 (NPT1/4 optional)
- Cushioning: Adjustable rubber buffer
- Body material: Aluminum alloy (anodized)
- Piston rod material: Stainless steel SUS304
- Seal material: NBR (nitrile butadiene rubber)
- Temperature range: -20℃ to 80℃
- Weight: 2.45kg (without accessories)
- Dimensions: 206mm(L) × 100mm(W) × 100mm(H)
- Mounting type: Basic fixed (ISO 15552 mounting optional)
- Rod end type: Female thread M10×1.25
- Max theoretical force: 706N @0.63MPa
- Lubrication: Pre-lubricated (recommended relubrication every 3,000km)
High-precision guided cylinder with space-saving design featuring integrated guide rails for enhanced lateral load capacity. The double-sealed piston rod prevents dust ingress in harsh environments. Optimized for vertical installation with ±0.05mm repeat positioning accuracy achieved through precision ground rods.
Typical Applications:
- Vertical press mechanisms in automotive assembly
- Precision alignment systems for semiconductor handling
- Packaging machine stopper actuators
- Automatic door locking mechanisms
- Glass panel positioning in electronics manufacturing
Installation note:
Requires minimum 5μm filtered air supply. For horizontal mounting,
reduce max speed to 70% of rated capacity. Lubricate through air
port using ISO VG32 hydraulic oil monthly. Maintain 15mm clearance
behind cylinder for rod extension.
Optional Accessories:
- Magnetic sensor kit ATE-MD10 (IP67 rated)
- Rod lock mechanism ATE-LK100
- Heat-resistant seal upgrade (up to 120℃)
- Anti-vibration mounting brackets
| Property | Property Value |
|---|---|
| sku | ATE100X25B |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | G1/8 |
| Piston Rod Thread Type | External Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 100mm |
| Stroke | <25 mm> |
