Airtac ATQ Single Acting Thin Cylinder ATQ12X10B
2. Features C-shaped retaining ring fixation for cylinder body and end covers, coupled with a riveted piston-rod structure for compact and reliable assembly;
3. Precision-honed cylinder bore ensures wear resistance and exceptional durability;
4. Extended front cover guide distance delivers superior guiding performance;
5. Space-optimized profile effectively minimizes installation space requirements;
6. Integrated peripheral sensor groove enables convenient proximity sensor mounting;
7. Multiple optional mounting accessories available for versatile configurations;
Category: Thin Cylinders | Brand: AIRTAC | Series: ATQ
AirTAC ATQ12X10B Single-Acting Compact Cylinder Specifications
- Model: ATQ12X10B
- Type: Single-acting spring return (piston type)
- Bore size: Φ12mm
- Stroke: 10mm (customizable 1-50mm)
- Operation: Air pressure extension / Spring retraction
- Working pressure: 0.05-0.9 MPa
- Temperature range: -20℃ to 80℃ (NBR seals)
- Cushioning: Rubber buffer + adjustable cushion screw
- Mounting: Basic type (no flange)
- Port size: M5x0.8 (dual ports)
- Seal material: NBR standard (optional FKM for oil resistance)
- Piston rod material: Stainless steel SUS304
- Weight: 72g ±2g (without accessories)
- Dimensions: 47mm(L) × 20mm(W) × 12mm(H)
- Rod thread: M4x0.7 external thread
- Repeat accuracy: ±0.1mm
- Max speed: 500mm/s
Ultra-slim profile cylinder (only 12mm height) designed for space-constrained automation systems. Features dual air ports for flexible piping and anti-rotation piston rod for precise positioning. Optional magnetic piston version (ATQ12X10B-M) for position sensing. Maintenance-free operation with self-lubricating guides.
- PCB handling robots in electronics manufacturing
- Micro-dosing valves in pharmaceutical packaging
- Lens positioning systems in optical equipment
- Clamping mechanisms in CNC tool changers
- Vending machine currency acceptors
Installation tips:
Use C-shaped mounting brackets (sold separately) for secure fixation.
Maintain 0.5-1mm clearance between cylinder body and machine frame
to prevent deformation. Lubricate with ISO VG32 turbine oil if used
in continuous high-cycle applications (>1 million cycles/year).
| Property | Property Value |
|---|---|
| sku | ATQ12X10B |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | External Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 12mm |
| Stroke | <10mm> |
