Airtac ATQ Single Acting Thin Cylinder ATQ12X20
2. Features C-shaped retaining ring fixation for cylinder body and end covers, coupled with a riveted piston-rod structure for compact and reliable assembly;
3. Precision-honed cylinder bore ensures wear resistance and exceptional durability;
4. Extended front cover guide distance delivers superior guiding performance;
5. Space-optimized profile effectively minimizes installation space requirements;
6. Integrated peripheral sensor groove enables convenient proximity sensor mounting;
7. Multiple optional mounting accessories available for versatile configurations;
Category: Thin Cylinders | Brand: AIRTAC | Series: ATQ
AirTAC ATQ Series Single-Acting Compact Cylinder ATQ12X20 Specifications
- Model: ATQ12X20
- Type: Single-acting spring return (piston type)
- Bore size: 12mm
- Stroke: 20mm (±1mm standard)
- Operating pressure: 0.05–0.9 MPa
- Ambient temperature: -20℃ to 80℃
- Port thread: M5×0.8 (standard) / G1/8 optional
- Cushioning: Fixed cushion rubber
- Mounting type: Basic (no bracket) / Foot-mount optional
- Piston material: Aluminum alloy (hard anodized)
- Rod material: Stainless steel SUS304
- Seal material: NBR (standard) / Fluororubber (FKM) optional
- Weight: 0.15kg (excluding accessories)
- Dimensions (L×W×H):
- Body length: 53mm
- Total length (extended): 53mm + stroke = 73mm
- Width: 30mm
- Height: 30mm
- ISO standard compliance: ISO 6432 (mounting dimensions)
- Lubrication: Pre-lubricated (oil-free operation possible)
Ultra-slim cylinder optimized for space-constrained automation systems, featuring 43% reduced axial length compared to standard cylinders. The self-compensating seal design ensures stable operation under variable loads. Integrated air cushion prevents piston impact at stroke ends. Compatible with vacuum applications when paired with suction cups.
- PCB handling in electronics assembly lines
- Micro-dosing valves in pharmaceutical packaging
- Lens positioning mechanisms in optical equipment
- Sheet metal clamping in CNC feeders
- Lab-on-chip fluid control systems
Installation note:
For vertical mounting, maintain minimum 0.3MPa pressure to prevent piston drop.
Use C-shaped clevis (sold separately) for moment load applications. Lubricate every
500km stroke travel in high-cycle (>5Hz) operations.
| Property | Property Value |
|---|---|
| sku | ATQ12X20 |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 12mm |
| Stroke | <20mm> |
