Airtac ATQ Single Acting Thin Cylinder ATQ12X20B
2. Features C-shaped retaining ring fixation for cylinder body and end covers, coupled with a riveted piston-rod structure for compact and reliable assembly;
3. Precision-honed cylinder bore ensures wear resistance and exceptional durability;
4. Extended front cover guide distance delivers superior guiding performance;
5. Space-optimized profile effectively minimizes installation space requirements;
6. Integrated peripheral sensor groove enables convenient proximity sensor mounting;
7. Multiple optional mounting accessories available for versatile configurations;
Category: Thin Cylinders | Brand: AIRTAC | Series: ATQ
AirTAC ATQ12X20B Single-Acting Compact Cylinder Specifications
- Model: ATQ12X20B
- Type: Single-acting spring return (piston type)
- Bore size: 12mm
- Stroke: 20mm
- Operating pressure: 0.15–0.8 MPa
- Operating temperature: -20℃ to 80℃
- Port size: M5x0.8 (standard) / G1/8 optional
- Cushioning: Adjustable rubber buffer
- Mounting type: Basic foot mounting (ISO 6432 standard)
- Material: Aluminum barrel, hard-anodized piston rod (SUS304)
- Seal material: NBR (nitrile rubber)
- Weight: 0.15kg ±5%
- Dimensions: 50mm(L) × 22mm(W) × 22mm(H) (excluding rod)
- Rod extended length: 20mm stroke + 25mm base = 45mm total
- Lubrication: Pre-lubricated (non-re-lube design)
- Protection rating: IP40 (dust protected)
Ultra-slim pneumatic cylinder optimized for space-constrained automation systems. Features a wear-resistant chromium-plated piston rod and dual anti-rotation guide slots for precise linear motion. Requires 5μm filtered compressed air with 1-10 mg/m³ oil mist content. Maximum piston speed: 500mm/s.
- PCB handling robots in electronics manufacturing
- Micro-dosing valves in pharmaceutical packaging
- Optical lens positioning systems
- Compact clamping fixtures for CNC machines
- Laboratory sample tray indexers
Installation note:
Mount on flat surface with 0.05mm flatness tolerance. For vertical installations,
use supplemental guide mechanisms if lateral forces exceed 2N. Lubricate rod
every 500km travel distance in high-cycle applications.
| Property | Property Value |
|---|---|
| sku | ATQ12X20B |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | External Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 12mm |
| Stroke | <20mm> |
