Airtac ATQ Single Acting Thin Cylinder ATQ12X5S
2. Features C-shaped retaining ring fixation for cylinder body and end covers, coupled with a riveted piston-rod structure for compact and reliable assembly;
3. Precision-honed cylinder bore ensures wear resistance and exceptional durability;
4. Extended front cover guide distance delivers superior guiding performance;
5. Space-optimized profile effectively minimizes installation space requirements;
6. Integrated peripheral sensor groove enables convenient proximity sensor mounting;
7. Multiple optional mounting accessories available for versatile configurations;
Category: Thin Cylinders | Brand: AIRTAC | Series: ATQ
AirTAC ATQ12X5S Single-Acting Compact Cylinder Specifications
- Model: ATQ12X5S
- Type: Single-acting spring return (push type)
- Bore size: 12mm
- Stroke: 5mm (±0.5mm tolerance)
- Operating pressure: 0.05–0.9 MPa
- Cushioning: Rubber buffer (both ends)
- Port size: M5x0.8 (standard) with optional NPT1/8 adaptor
- Piston speed: 50–700 mm/s (optimal at 0.5 MPa)
- Ambient temperature: -20℃ to 80℃
- Material:
- Tube: Aluminum alloy (hard anodized)
- Piston rod: SUS304 stainless steel
- Seals: NBR (nitrile rubber)
- Weight: 0.12 kg (bare cylinder), 0.15 kg with accessories
- Dimensions: 50mm(L) × 34mm(W) × 12mm(H) (excluding rod extension)
- Mounting options: Basic type (no boss) with optional foot/wall mounts
- ISO standard: Compliant with ISO 6432 (miniature cylinders)
Ultra-slim profile cylinder (12mm height reduction vs standard models) designed for space-constrained automation. Features precision ground rod and anti-rotation piston for stable linear motion. Optional magnetic piston version (ATQ12X5S-M9) available for position sensing. Requires ISO VG32 hydraulic oil lubrication if used in high-cycle applications (>1 million cycles).
- PCB handling robots in electronics assembly
- Micro-dosing valves in pharmaceutical packaging
- Precision clamping in optical lens production
- Ventilation damper control in medical devices
- Compact jig positioning systems
Installation note:
Maintain ≤0.1mm lateral alignment tolerance during mounting. For vertical installations,
use spring-down orientation to prevent seal wear. Lubricate monthly with AirTAC PX-22
grease in dusty environments.
| Property | Property Value |
|---|---|
| sku | ATQ12X5S |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | <5mm> |
