Airtac ATQ Single Acting Thin Cylinder ATQ12X5SB
2. Features C-shaped retaining ring fixation for cylinder body and end covers, coupled with a riveted piston-rod structure for compact and reliable assembly;
3. Precision-honed cylinder bore ensures wear resistance and exceptional durability;
4. Extended front cover guide distance delivers superior guiding performance;
5. Space-optimized profile effectively minimizes installation space requirements;
6. Integrated peripheral sensor groove enables convenient proximity sensor mounting;
7. Multiple optional mounting accessories available for versatile configurations;
Category: Thin Cylinders | Brand: AIRTAC | Series: ATQ
AirTAC ATQ12X5SB Single-Acting Compact Cylinder Specifications
- Model: ATQ12X5SB
- Type: Single-acting spring return (push type)
- Bore size: 12mm
- Stroke: 5mm
- Operating pressure: 0.15–0.8 MPa
- Temperature range: -20℃ to 80℃
- Port size: M5x0.8 (dual ports)
- Mounting style: Standard bracket (optional flange)
- Cushion type: Rubber pad buffer
- Seal material: NBR (nitrile rubber)
- Repeat positioning accuracy: ±0.2mm
- Max piston speed: 500mm/s
- Protection rating: IP40
- Weight: 0.25kg (excluding accessories)
- Dimensions: 32mm(L) × 20mm(W) × 12mm(H) (body only)
- Full extended length: 37mm (stroke+body)
Ultra-slim pneumatic cylinder featuring 3mm wall thickness and anodized aluminum construction. The spring-return mechanism enables fail-safe retraction with 0.5N return force. Designed for high-frequency operations (up to 5 cycles/sec) with low friction guide bush. Includes anti-rotation pin (2mm diameter) for precision alignment.
- PCB handling robots in electronics manufacturing
- Micro-part ejection systems
- Medical device positioning mechanisms
- Precision valve actuation in analytical instruments
- Compact clamping fixtures for CNC tooling
Installation guidelines:
Maintain perpendicular mounting surface (flatness ≤0.1mm). Use 2x M3 mounting screws (torque ≤0.6N·m).
Lubricate with ISO VG32 hydraulic oil if operating below -10℃. Avoid side loads exceeding 2N.
- Speed controller ASC-1/8
- Rod end joint AJC12
- Magnetic sensor D-A93 (non-contact type)
| Property | Property Value |
|---|---|
| sku | ATQ12X5SB |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | <5mm> |
