Airtac ATQ Single Acting Thin Cylinder ATQ16X10
$20.43
Regular price
$27.93
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
ATQ16X10
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
ATQ Single-Acting Thin Cylinder
1. Complies with JIS industrial standards;
2. Features C-shaped retaining ring fixation for cylinder body and end covers, coupled with a riveted piston-rod structure for compact and reliable assembly;
3. Precision-honed cylinder bore ensures wear resistance and exceptional durability;
4. Extended front cover guide distance delivers superior guiding performance;
5. Space-optimized profile effectively minimizes installation space requirements;
6. Integrated peripheral sensor groove enables convenient proximity sensor mounting;
7. Multiple optional mounting accessories available for versatile configurations;
Category: Thin Cylinders | Brand: AIRTAC | Series: ATQ
Installation note:
Lubricate with ISO VG32 hydraulic oil before initial use.
Avoid side load exceeding 0.3N·m. For vertical mounting,
position piston rod downward to prevent debris accumulation.
2. Features C-shaped retaining ring fixation for cylinder body and end covers, coupled with a riveted piston-rod structure for compact and reliable assembly;
3. Precision-honed cylinder bore ensures wear resistance and exceptional durability;
4. Extended front cover guide distance delivers superior guiding performance;
5. Space-optimized profile effectively minimizes installation space requirements;
6. Integrated peripheral sensor groove enables convenient proximity sensor mounting;
7. Multiple optional mounting accessories available for versatile configurations;
Category: Thin Cylinders | Brand: AIRTAC | Series: ATQ
AirTAC ATQ16X10 Single-Acting Compact Cylinder Specifications
- Model: ATQ16X10
- Type: Single-acting (spring return)
- Bore size: 16mm
- Stroke: 10mm
- Operating pressure: 0.15–0.8 MPa
- Port size: M5x0.8 (standard) / PT1/8 optional
- Weight: 0.12kg ±5%
- Dimensions: 40mm(L) × 22mm(W) × 16mm(H)
- Piston material: Hard anodized aluminum alloy
- Seal material: NBR (nitrile rubber)
- Temperature range: -20℃ to 80℃
- Operation mode: Push type (extends with air pressure)
- Cushioning: Fixed rubber buffer
- Mounting options: Foot mounting / basic flange
- Protection rating: IP65 (dust-tight & water jet resistant)
Ultra-slim profile cylinder optimized for space-constrained automation systems. Features chrome-plated piston rod with integrated scraper for contamination resistance. Requires 1-3μm filtered compressed air (ISO 8573-1). Maximum theoretical thrust force: 14.5N at 0.6MPa.
Typical Applications:
- PCB handling robots in electronics manufacturing
- Medical device clamping mechanisms
- Textile machine thread tension control
- Precision valve actuation in cleanrooms
- Semiconductor wafer positioning systems
Installation note:
Lubricate with ISO VG32 hydraulic oil before initial use.
Avoid side load exceeding 0.3N·m. For vertical mounting,
position piston rod downward to prevent debris accumulation.
| Property | Property Value |
|---|---|
| sku | ATQ16X10 |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 16mm |
| Stroke | <10mm> |
