Airtac ATQ Single Acting Thin Cylinder ATQ16X10S
2. Features C-shaped retaining ring fixation for cylinder body and end covers, coupled with a riveted piston-rod structure for compact and reliable assembly;
3. Precision-honed cylinder bore ensures wear resistance and exceptional durability;
4. Extended front cover guide distance delivers superior guiding performance;
5. Space-optimized profile effectively minimizes installation space requirements;
6. Integrated peripheral sensor groove enables convenient proximity sensor mounting;
7. Multiple optional mounting accessories available for versatile configurations;
Category: Thin Cylinders | Brand: AIRTAC | Series: ATQ
AirTAC ATQ16X10S Single-Acting Compact Cylinder Specifications
- Model: ATQ16X10S
- Type: Single-acting spring return (push type)
- Bore size: 16mm
- Stroke: 10mm (±1mm tolerance)
- Operating pressure: 0.05–0.9 MPa
- Port size: M5x0.8 (standard) with 2x Ø4mm pneumatic ports
- Cushioning: Rubber buffer (non-adjustable)
- Seal material: NBR (Nitrile) with wear-resistant piston ring
- Temperature range: -20℃ to 80℃
- Weight: 85g ±3g
- Dimensions:
- Length: 59mm (including fittings)
- Width: 24mm (maximum body width)
- Height: 16mm (excluding mounting accessories)
- Rod thread: M4x0.7 external thread
- Mounting: 2x M3 threaded holes (standard pattern)
- Built-in magnet: No (requires separate magnetic sensor for position detection)
- Protection rating: IP40 (dust protected)
Ultra-slim profile cylinder optimized for space-constrained automation systems. Features precision honed aluminum tube with hard anodized finish for smooth operation. The double-sealed piston design prevents internal leakage even under low-pressure conditions (≥0.05MPa). Requires lubrication-free operation with filtered air (5-50μm filter recommended).
- PCB handling robots in electronics manufacturing
- Precision clamping mechanisms for CNC fixtures
- Medical device assembly automation
- Compact packaging machine ejectors
- Semiconductor wafer processing equipment
Installation tip:
Maintain 0.5-1mm clearance between cylinder body and adjacent components to prevent heat buildup.
For vertical mounting, position spring side downward to prevent piston rod sagging. Lubricate rod with ISO VG32 hydraulic oil if used in high-cycle applications (>1M cycles/year).
| Property | Property Value |
|---|---|
| sku | ATQ16X10S |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | S-Magnetic |
| Bore Diameter | 16mm |
| Stroke | <10mm> |
