Airtac ATQ Single Acting Thin Cylinder ATQ16X10SB
2. Features C-shaped retaining ring fixation for cylinder body and end covers, coupled with a riveted piston-rod structure for compact and reliable assembly;
3. Precision-honed cylinder bore ensures wear resistance and exceptional durability;
4. Extended front cover guide distance delivers superior guiding performance;
5. Space-optimized profile effectively minimizes installation space requirements;
6. Integrated peripheral sensor groove enables convenient proximity sensor mounting;
7. Multiple optional mounting accessories available for versatile configurations;
Category: Thin Cylinders | Brand: AIRTAC | Series: ATQ
AirTAC ATQ16X10SB Single-Acting Slim Cylinder Specifications
- Model: ATQ16X10SB
- Type: Single-acting spring return (piston type)
- Bore size: 16mm
- Stroke: 10mm (standard)
- Operating pressure: 0.05–0.9 MPa
- Operating temperature: -20℃ to 80℃
- Cushion type: Fixed rubber buffer
- Mounting style: Basic type (no built-in mounting)
- Port size: M5x0.8 (dual ports)
- Material:
- Cylinder tube: Aluminum alloy (hard anodized)
- Piston rod: Stainless steel (SUS304)
- Seals: NBR (nitrile rubber)
- Weight: 0.12kg ±2%
- Dimensions:
- Length: 57mm (full retracted)
- Width: 30mm (body diameter)
- Height: 16mm (excluding rod)
- Rod thread: M4x0.7 (external)
- ISO standard: 6432 (VDMA 24562)
- RoHS compliance: Yes
Ultra-compact pneumatic cylinder optimized for space-constrained automation systems. Features a low 0.5mm installation tolerance and anti-rotation piston rod design. The aluminum alloy body with hard coat oxidation resists chemical corrosion in industrial environments. Requires 40μm filtered air and ISO VG32 turbine oil lubrication (non-lube version available on request).
- PCB handling robots in electronics manufacturing
- Micro-precision clamping in watchmaking
- Valve actuation in analytical instruments
- Paper feed mechanisms in compact printers
- Positioning stages in optical alignment systems
Installation note:
Use precision alignment jigs during mounting. Maximum allowable lateral load: 2.5N.
For vertical mounting, reduce operating pressure by 20% to compensate for spring force.
| Property | Property Value |
|---|---|
| sku | ATQ16X10SB |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Bore Diameter | 16mm |
| Stroke | <10mm> |
