Airtac ATQ Single Acting Thin Cylinder ATQ16X15
2. Features C-shaped retaining ring fixation for cylinder body and end covers, coupled with a riveted piston-rod structure for compact and reliable assembly;
3. Precision-honed cylinder bore ensures wear resistance and exceptional durability;
4. Extended front cover guide distance delivers superior guiding performance;
5. Space-optimized profile effectively minimizes installation space requirements;
6. Integrated peripheral sensor groove enables convenient proximity sensor mounting;
7. Multiple optional mounting accessories available for versatile configurations;
Category: Thin Cylinders | Brand: AIRTAC | Series: ATQ
AirTAC ATQ16X15 Single-Acting Compact Cylinder Specifications
- Model: ATQ16X15
- Type: Single-acting (spring return)
- Bore size: 16mm
- Stroke: 15mm
- Operating pressure: 0.05–0.9 MPa
- Port size: M5x0.8 (standard) / NPT1/8 optional
- Cushion type: Fixed buffer
- Temperature range: -10℃ to 80℃
- Mounting style: Basic type (no built-in mounts)
- Material: Aluminum alloy body, stainless steel piston rod
- Seal material: NBR rubber (standard) / PU optional
- Weight: 0.12kg
- Dimensions: 58mm(L) × 28mm(W) × 28mm(H) (excluding rod)
- Rod thread: M5x0.8 external thread
- Max theoretical force: 18.1N @0.5MPa
- ISO standard: 6432 compliant
Ultra-slim profile cylinder (height = bore size) with 50% reduced length compared to standard models. Features anti-rotation guide for precise linear motion and wear-resistant rod bearing. Ideal for space-constrained automation requiring repetitive short-stroke movements. Compatible with guided units for multi-axis applications.
- PCB handling robots in electronics assembly
- Micro-dosing valves in pharmaceutical equipment
- Clamping mechanisms in SMT pick-and-place machines
- Actuation of inspection probes in automotive test rigs
- Paper feed mechanisms in office automation devices
Installation note:
Maintain 0.5mm minimum clearance between rod end and load during alignment.
Lubricate with ISO VG32 hydraulic oil before first use. Max lateral load: 2.5N.
| Property | Property Value |
|---|---|
| sku | ATQ16X15 |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 16mm |
| Stroke | <15mm> |
