Airtac ATQ Single Acting Thin Cylinder ATQ16X20B
2. Features C-shaped retaining ring fixation for cylinder body and end covers, coupled with a riveted piston-rod structure for compact and reliable assembly;
3. Precision-honed cylinder bore ensures wear resistance and exceptional durability;
4. Extended front cover guide distance delivers superior guiding performance;
5. Space-optimized profile effectively minimizes installation space requirements;
6. Integrated peripheral sensor groove enables convenient proximity sensor mounting;
7. Multiple optional mounting accessories available for versatile configurations;
Category: Thin Cylinders | Brand: AIRTAC | Series: ATQ
AirTAC ATQ16X20B Single-Acting Compact Cylinder Specifications
- Model: ATQ16X20B
- Type: Single-acting spring return (piston returns via built-in spring)
- Bore size: 16mm
- Stroke: 20mm (±1mm tolerance)
- Operating pressure: 0.05–0.9 MPa
- Operating temperature: -20℃ to 80℃
- Port size: M5x0.8 (standard) with 1/8" NPT optional
- Cushioning: Adjustable rubber buffer
- Seal material: NBR (nitrile) with wear-resistant guide rings
- Mounting style: Basic type (no built-in mounts) with optional accessories
- Weight: 0.15kg (excluding accessories)
- Dimensions:
- Total length (extended): 50mm
- Body diameter: 32mm
- Mounting hole spacing: 20mm (center-to-center)
- Rod thread: M6x1.0
- Protection class: IP54 (standard sealing)
- Lubrication: Pre-lubricated (maintenance-free for 2000km operation)
Ultra-slim profile pneumatic cylinder optimized for space-constrained automation systems. Features anodized aluminum construction with chrome-plated piston rod (hardness HRC 45-50). The T-slot design allows easy sensor mounting for position detection. Requires 40μm filtered air with 1-10% oil mist content recommended.
- PCB handling robots in electronics assembly
- Medical device lid clamping mechanisms
- Textile machinery thread tension control
- Semiconductor wafer cassette positioning
- Automated door locking systems
Installation guidelines:
Maximum side load ≤5N. For vertical mounting, use stroke-end locking nuts.
Lubricate rod end weekly in high-cycle applications (>500 cycles/min).
Avoid extended dwell time at stroke ends to prevent spring fatigue.
| Property | Property Value |
|---|---|
| sku | ATQ16X20B |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | External Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 16mm |
| Stroke | <20mm> |
