Airtac ATQ Single Acting Thin Cylinder ATQ16X20SB
$25.55
Regular price
$33.05
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
ATQ16X20SB
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
ATQ Single-Acting Thin Cylinder
1. Complies with JIS industrial standards;
2. Features C-shaped retaining ring fixation for cylinder body and end covers, coupled with a riveted piston-rod structure for compact and reliable assembly;
3. Precision-honed cylinder bore ensures wear resistance and exceptional durability;
4. Extended front cover guide distance delivers superior guiding performance;
5. Space-optimized profile effectively minimizes installation space requirements;
6. Integrated peripheral sensor groove enables convenient proximity sensor mounting;
7. Multiple optional mounting accessories available for versatile configurations;
Category: Thin Cylinders | Brand: AIRTAC | Series: ATQ
Installation note:
Maintain 0.5mm minimum clearance between rod end and load during alignment.
For vertical mounting, use external guides to prevent piston rotation.
Maximum side load: 2.5N at full extension.
2. Features C-shaped retaining ring fixation for cylinder body and end covers, coupled with a riveted piston-rod structure for compact and reliable assembly;
3. Precision-honed cylinder bore ensures wear resistance and exceptional durability;
4. Extended front cover guide distance delivers superior guiding performance;
5. Space-optimized profile effectively minimizes installation space requirements;
6. Integrated peripheral sensor groove enables convenient proximity sensor mounting;
7. Multiple optional mounting accessories available for versatile configurations;
Category: Thin Cylinders | Brand: AIRTAC | Series: ATQ
AirTAC ATQ16X20SB Single-Acting Compact Cylinder Specifications
- Model: ATQ16X20SB
- Type: Single-acting spring return (piston type)
- Bore size: 16mm
- Stroke: 20mm (±1mm tolerance)
- Operating pressure: 0.05–0.8 MPa
- Ambient temperature: -20℃ to 80℃
- Cushioning: Fixed rubber buffer
- Port size: M5×0.8 (DIN/ISO G1/8 optional)
- Piston speed: 50–700 mm/s (optimal range 100–300 mm/s)
- Mounting style: Basic (no pre-mounted brackets)
- Seal material: NBR + PUR composite seals
- Weight: 135g ±5g
- Dimensions:
- Length: 62mm (full retraction)
- Width: 32mm (body diameter)
- Height: 32mm (square body profile)
- Rod end: Female M6×1.0 thread
- Lubrication: Pre-lubricated (DOP mist prohibited)
Ultra-slim profile pneumatic cylinder optimized for space-constrained automation applications. Features anodized aluminum construction with scratch-resistant coating and dual sealing system for dry/wet environments. Requires 40μm filtered air with ≤5% oil content (ISO 8573-1 class 4).
Typical Applications:
- PCB handling robots in electronics assembly
- Medical device clamping mechanisms
- Photovoltaic panel positioning systems
- Food packaging machine ejectors
- 3D printer filament tensioners
Installation note:
Maintain 0.5mm minimum clearance between rod end and load during alignment.
For vertical mounting, use external guides to prevent piston rotation.
Maximum side load: 2.5N at full extension.
| Property | Property Value |
|---|---|
| sku | ATQ16X20SB |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Bore Diameter | 16mm |
| Stroke | <20mm> |
