Airtac ATQ Single Acting Thin Cylinder ATQ16X5B
2. Features C-shaped retaining ring fixation for cylinder body and end covers, coupled with a riveted piston-rod structure for compact and reliable assembly;
3. Precision-honed cylinder bore ensures wear resistance and exceptional durability;
4. Extended front cover guide distance delivers superior guiding performance;
5. Space-optimized profile effectively minimizes installation space requirements;
6. Integrated peripheral sensor groove enables convenient proximity sensor mounting;
7. Multiple optional mounting accessories available for versatile configurations;
Category: Thin Cylinders | Brand: AIRTAC | Series: ATQ
AirTAC ATQ16X5B Single-Acting Compact Cylinder Specifications
- Model: ATQ16X5B
- Type: Single-acting (spring return), slim profile
- Bore size: 16 mm
- Stroke: 5 mm (±0.5 mm adjustment range)
- Operating pressure: 0.15–0.8 MPa
- Operating temperature: -20℃ to 80℃
- Port size: M5x0.8 (standard), optional NPT1/8 adapter
- Cushioning: Elastic rubber bumper
- Mounting style: Basic non-magnetic stainless steel body with axial mounting holes (tapped M4x0.7)
- Seal material: Heat-resistant NBR (Nitrile) seals
- Piston material: Anodized aluminum alloy
- Rod material: Stainless steel SUS304
- Weight: 0.12 kg (excluding accessories)
- Dimensions: 35mm (L) × 40mm (W) × 16mm (H) (body only)
- Max theoretical force: 12.6 N @ 0.6 MPa
- Air consumption: 0.12 L/stroke @ 0.5 MPa
- ISO certification: Compliant with ISO 6432 standards
Ultra-compact pneumatic cylinder optimized for space-constrained automation systems. Features precision-ground rod guides for smooth operation (≤0.05mm radial play) and corrosion-resistant construction. Requires 40μm filtered dry air with recommended lubrication (ISO VG32 grade). Includes built-in magnetic field for sensor compatibility.
- PCB handling robots in electronics manufacturing
- Micro-dosing valves in pharmaceutical equipment
- Precision clamping mechanisms for optical lens production
- Vending machine currency acceptors
- Laboratory sample positioning stages
Installation note:
Maintain ≤0.1mm alignment tolerance during mounting. For vertical installations,
use spring-side down configuration to prevent piston seizure. Lubricate monthly
under continuous operation conditions.
| Property | Property Value |
|---|---|
| sku | ATQ16X5B |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | External Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 16mm |
| Stroke | <5mm> |
