Airtac B01-MAC Series Special Purpose Cylinder B01-MAC32X125SU
AirTAC B01-MAC32X125SU Special Purpose Cylinder Specifications
- Model: B01-MAC32X125SU
- Type: Compact round cylinder with magnetic piston
- Bore size: 32mm
- Stroke: 125mm
- Operating pressure: 0.05–1.0 MPa
- Port size: M5×0.8 (Standard) / NPT1/8 (Optional)
- Piston speed: 50–700 mm/s
- Cushioning type: Adjustable rubber buffer
- Ambient temperature: -10℃ to 80℃
- Seal material: Polyurethane (PU) with wear-resistant ring
- Rod material: Stainless steel (SUS304)
- Mounting type: Basic (no pre-mounting accessories)
- Weight: 1.85 kg ±2%
- Dimensions:
- Extended length: 268mm
- Retracted length: 143mm
- Body diameter: 40mm
- Rod end thread: M12×1.25
- IP rating: IP54 (standard sealing)
High-precision industrial cylinder featuring integrated magnet for position sensing compatibility. The anodized aluminum body provides corrosion resistance in humid environments, while the chrome-plated piston rod ensures smooth operation. Requires ISO 8573-1:2010 Class 3-4-3 compressed air quality.
- Precision clamping in CNC machining centers
- Material handling in semiconductor FOUP transport systems
- Automated packaging line pusher mechanisms
- Pharmaceutical blister packaging machines
- Robotic welding fixture positioning
Installation note:
For optimal sensor performance, maintain 1-2mm gap between cylinder body and magnetic switch.
Lubricate with ISO VG32 hydraulic oil during maintenance. Avoid side load exceeding 30N.
| Property | Property Value |
|---|---|
| sku | B01-MAC32X125SU |
