Airtac B01-SDAD Dedicated Cylinder B01-SDAD32X30B
AirTAC B01-SDAD32X30B Special Purpose Cylinder Specifications
- Model: B01-SDAD32X30B
- Type: Compact double-acting cylinder (ISO 6432 standard)
- Bore size: 32mm (±0.1mm tolerance)
- Stroke: 30mm (adjustable cushioning)
- Operating pressure: 0.1–1.0 MPa
- Piston speed: 50–800 mm/s (lubricated condition)
- Port size: M5x0.8 (G1/8 adaptor optional)
- Cushioning: Adjustable rubber buffers (both ends)
- Mounting: Front flange (NF series pattern) with 4xM5 threaded holes
- Rod end: M6x1.0 external thread
- Seal material: NBR + PU combination
- Temperature range: -20℃ to 80℃ (dry air required below 0℃)
- Weight: 520g ±3% (without accessories)
- Dimensions: 136mm(L) × 42mm(W) × 42mm(H) (fully retracted)
- Protection rating: IP67 (rod extension area IP54)
- Lubrication: Pre-lubricated (Use ISO VG32 turbine oil if replenished)
High-precision mini cylinder with integrated shock absorption, featuring chromium-plated piston rod (HRC 45-50 hardness) and aluminum alloy barrel. Designed for repetitive positioning tasks requiring minimal space and vibration control. Includes built-in magnet for position sensing compatibility.
- PCB component insertion machines
- Pharmaceutical blister packaging systems
- Robotic end-effector clamping mechanisms
- Cleanroom automation equipment
- Precision valve actuation in food processing
Installation guidelines:
Ensure 0.5mm minimum clearance between rod end and load during alignment.
For vertical mounting, use locking nuts on piston rod threads.
Maximum side load: 15N at full extension.
