Airtac B01-SDAD Dedicated Cylinder B01-SDAD32X40
AirTAC B01-SDAD32X40 Special Purpose Cylinder Specifications
- Model: B01-SDAD32X40
- Type: Compact double-acting pneumatic cylinder
- Bore size: 32mm
- Stroke: 40mm
- Operating pressure: 0.05–1.0 MPa
- Piston rod diameter: 12mm
- Cushioning type: Adjustable hydraulic buffer (both ends)
- Port size: M5x0.8 (standard), G1/8 optional
- Operating temperature: -10℃ to 80℃
- Seal material: NBR + PU combination
- Ambient humidity: ≤95% RH
- Weight: 0.82kg ±5%
- Dimensions:
- Total length (retracted): 134mm
- Body diameter: 32mm ±0.5mm
- Mounting base: 50mm × 32mm
- Rod end thread: M10×1.25
- ISO standard: 6432 compliant
High-precision industrial cylinder featuring wear-resistant chromium-plated piston rod and low-friction seals. The dual-chamber buffer system minimizes end-impact noise while maintaining positioning accuracy (±0.2mm repeatability). Designed for vertical/horizontal mounting with multiple accessory options (clevis, flange, or foot mounting kits).
- High-speed pick-and-place automation (800-1200 cycles/hour)
- Precision clamping in CNC fixture systems
- Material handling in cleanroom environments
- Packaging machine ejection mechanisms
- Semiconductor wafer processing equipment
Maintenance note:
Lubricate with ISO VG32 hydraulic oil every 500,000 cycles.
Avoid side-load forces exceeding 30N. For vertical mounting,
install with rod end downward to prevent moisture accumulation.
