Airtac B03-4M Explosion-proof Solenoid Valve B03-4M31010B
AirTAC B03-4M31010B Explosion-Proof Solenoid Valve Specifications
- Model: B03-4M31010B
- Type: 3/2-way normally closed (direct-acting with explosion-proof housing)
- Explosion-proof rating: Ex d IIB T4 Gb (ATEX/IECEx certified)
- Port size: PT1/4" (NPT1/4" optional)
- Operating pressure: 0.1–1.0 MPa
- Voltage options: DC24V (±10%), AC220V 50/60Hz
- Max operating frequency: 5 Hz
- Flow coefficient (Cv): 1.6
- Ambient temperature: -20℃ to +60℃
- Fluid temperature: -5℃ to +80℃
- Seal material: Fluororubber (FKM)
- Housing material: Aluminum alloy (surface anodized)
- Protection rating: IP65 (dust-tight & water jet resistant)
- Weight: 1.2 kg ±5%
- Dimensions: 120mm(L) × 75mm(W) × 95mm(H)
- Electrical connection: DIN43650 Form A with explosion-proof conduit entry
- Power consumption: ≤2.5W (DC) / ≤5VA (AC)
Heavy-duty explosion-proof solenoid valve engineered for hazardous environments requiring ATEX Zone 1/21 compliance. Features flame-path containment design with anti-static coating and reinforced coil protection. Requires intrinsically safe circuit pairing (Barrier ≤30V/100mA). Includes manual override and status indicator.
- Petrochemical processing equipment
- Coal mine ventilation control systems
- Grain silo pneumatic conveying
- Paint spray booth automation
- Offshore platform gas detection systems
Installation protocol:
Use certified explosion-proof conduits (minimum M20x1.5 thread). Maintain 50mm clearance
from heat sources. Perform monthly diaphragm integrity checks in corrosive environments.
Safety notice:
Always de-energize system before maintenance. Grounding resistance must be <4Ω.
Not compatible with acetylene or hydrogen-rich atmospheres.
