Airtac B03-4V Explosion-Proof Solenoid Valve B03-4V22006B
The AirTAC Airtac B03-4V Explosion-Proof Solenoid Valve B03-4V22006B is a genuine 5/2-way solenoid valve solenoid valve with 22006B ports and an effective area of See datasheet (Cv —). It is an internally piloted spool valve that directs compressed air to double-acting cylinders and actuators.
- Valve type5/2-way
- FunctionSolenoid valve
- Port size22006B
- Effective areaSee datasheet
- Flow (Cv)—
- Series4V
About the Airtac B03-4V Explosion-Proof Solenoid Valve B03-4V22006B
The B03-4V22006B is AirTAC's explosion-proof build of the 4V220-06B, a double-solenoid 5/2-way valve with a memory function. It directs compressed air to double-acting cylinders and actuators, holding its last pulsed position without power. This version is engineered for use in hazardous or flammable atmospheres, making it a critical component for facilities that require specialized equipment.
This valve delivers a 17 mm² effective area (Cv 1.0) and suits cylinders in the ~32-50 mm range. With a DC24V coil drawing just 3.0 W and a response time of 0.05 s or less, it offers efficient and rapid actuation. The B03- prefix indicates the explosion-proof construction, but please confirm the exact protection rating and certification for your specific zone with us before ordering.
Airtac B03-4V Explosion-Proof Solenoid Valve B03-4V22006B Technical Specifications
| Model | Airtac B03-4V Explosion-Proof Solenoid Valve B03-4V22006B |
|---|---|
| Series | 4V solenoid valve (spool type) |
| Valve type | 5/2-way |
| Function | Solenoid valve |
| Port size | 22006B |
| Exhaust port | 22006B |
| Effective area (Cv) | See datasheet (Cv —) |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Pilot type | Internal / external pilot |
| Operating pressure | 0.15 – 0.8 MPa |
| Proof pressure | 1.2 MPa |
| Max frequency | See datasheet |
| Response time | ≤ 0.05 s (activating) |
| Temperature | -20 to +70 °C |
| Body material | Aluminum alloy |
| Weight | See datasheet |
Specifications follow the official AirTAC 4V series datasheet. Lubrication not required. Confirm coil voltage and thread (PT / NPT / G) against the product label before wiring.
Flow & Coil Options
| Effective area | See datasheet |
|---|---|
| Flow coefficient | Cv — |
| Response time | ≤ 0.05 s |
| Coil power | AC 3.5–4.5 VA · DC 2.5–3.0 W |
| Protection / insulation | IP65 (DIN40050), B-class |
| Voltage options | DC24V, DC12V, AC110V, AC220V |
| Manual override | Yes (locking / non-locking) |
Size the valve so effective area / Cv is not the bottleneck for your cylinder bore and speed. Undersized valves slow the actuator. Note 5/3 (center) versions have a smaller effective area than the 5/2 of the same body size.
Model Code: Airtac B03-4V Explosion-Proof Solenoid Valve B03-4V22006B
| 4V | Solenoid valve, spool type, 4-series. |
|---|---|
| B | Body size (4V) — sets port & flow. |
| 0 | Function: 1 = single 5/2, 2 = double 5/2, 3 = 5/3. |
| -22006B | Port thread: M5 / 06=1/8" / 08=1/4" / 10=3/8" / 15=1/2". |
Related: 4VB10 (single), 4VB20 (double), 4VB30C/E/P (5/3 center). Add the voltage suffix when ordering.
