Airtac B06-MAC Battery-Specific Cylinder B06-MAC16X100SCA
AirTAC B06-MAC16X100SCA Battery-Powered Cylinder Specifications
- Model: B06-MAC16X100SCA
- Type: Double-acting battery cylinder (rodless type)
- Bore size: 16mm
- Stroke: 100mm
- Operating pressure: 0.05–0.7 MPa
- Battery compatibility: 12-24V DC systems
- Max thrust: 32N at 0.5MPa
- Speed range: 50–500mm/s
- Buffer type: Rubber cushion (adjustable)
- Seal material: NBR/PU hybrid seals
- Temperature range: -10℃ to 80℃
- Weight: 850g ±5% (excluding battery pack)
- Dimensions: 195mm(L) × 32mm(W) × 32mm(H)
- Mounting type: Standard ISO 15552 accessory compatibility
- Protection rating: IP54 (IP67 with optional kit)
Compact cordless pneumatic actuator designed for mobile automation solutions. Features integrated battery management with low-voltage protection and power-saving sleep mode (0.5W standby consumption). Precision-machined aluminum alloy body with anti-rotation guide slot ensures stable linear motion. Includes magnetic piston for position sensing compatibility.
- Portable medical diagnostic equipment
- AGV (Automated Guided Vehicle) clamping systems
- Solar-powered agricultural actuators
- Mobile robotic assembly stations
- Battery-operated packaging machines
Installation note:
Requires monthly lubrication (VG32 hydraulic oil recommended).
Maintain 15mm clearance around cylinder body for heat dissipation.
Battery terminals must be sealed with provided silicone caps in humid environments.
| Property | Property Value |
|---|---|
| sku | B06-MAC16X100SCA |
