Airtac B06-SDA Battery Dedicated Cylinder B06-SDA32X50SB
AirTAC B06-SDA Series Battery-Optimized Cylinder - B06-SDA32X50SB
- Model: B06-SDA32X50SB
- Type: Double-acting pneumatic cylinder (battery operation optimized)
- Bore size: 32mm
- Stroke: 50mm
- Operating pressure: 0.05–0.7 MPa
- Battery compatibility: 12-24V DC systems
- Piston rod material: Hard chrome-plated steel
- Cylinder tube: Aluminum alloy (anodized finish)
- Seal material: Polyurethane (PU) with low friction design
- Temperature range: -10℃ to 80℃
- Weight: 1.65kg ±3%
- Dimensions: 146mm(L) × 45mm(W) × 45mm(H) (retracted state)
- Extended length: 196mm (full stroke)
- Max thrust: 226N @0.5MPa
- Speed range: 50–800mm/s
- Protection rating: IP54 (standard), IP67 optional
- Mounting type: Basic foot, front flange, or rear pivot options
Energy-efficient pneumatic cylinder specifically engineered for battery-powered automation systems. Features reduced air consumption (30% less than standard models) and optimized seal geometry for smooth low-pressure operation. Integrated shock absorbers prevent end-position impact damage in mobile applications.
- Portable medical equipment actuators
- AGV (Automated Guided Vehicle) lifting mechanisms
- Solar-powered agricultural actuators
- Mobile battery-pack pneumatic systems
- Lightweight robotic arm joints
- Outdoor IoT-enabled automation devices
Installation recommendation:
For vertical installations exceeding 45° angle, use optional position-lock accessory (B06-LK2).
Lubricate with ISO VG32 hydraulic oil during maintenance cycles.
| Property | Property Value |
|---|---|
| sku | B06-SDA32X50SB |
