Airtac B06-SDA Battery Dedicated Cylinder B06-SDA40X20SB
AirTAC B06-SDA40X20SB Battery-Powered Cylinder Specifications
- Model: B06-SDA40X20SB (Battery Series Special Design)
- Bore size: 40mm
- Stroke: 20mm
- Operating pressure: 0.1–0.8 MPa
- Temperature range: -10℃ to 70℃
- Cushioning: Adjustable pneumatic cushion (both ends)
- Piston material: Hard anodized aluminum alloy
- Rod material: Stainless steel (SUS304)
- Seal type: Nitrile rubber (NBR) with wear-resistant ring
- Repeat accuracy: ±0.1mm
- Max speed: 500 mm/s
- Mounting style: Standard ISO/VDS 24552 base mount (optional side/face mounts)
- Port size: M5x0.8 (standard), G1/8 optional
- Weight: 1.23 kg (including mounting accessories)
- Dimensions: 120mm(L) × 54mm(W) × 54mm(H) (full retracted length)
Compact pneumatic cylinder optimized for battery-operated systems, featuring ultra-low friction design (≤0.05 dynamic friction coefficient) and energy-efficient operation. Integrated magnetic piston enables position feedback compatibility. Corrosion-resistant construction with IP67 protection rating ensures reliability in harsh environments. Requires Class 4 filtration (5μm filter).
- Mobile robotic assembly systems
- Portable medical compression devices
- Solar-powered agricultural actuators
- Electric vehicle battery pack handling
- Automated guided vehicle (AGV) clamping mechanisms
- Energy harvesting equipment
Installation guidelines:
Maintain 0.5mm minimum clearance around cylinder body for thermal expansion.
Lubricate with ISO VG32 turbine oil (NBR-compatible) every 50km of cumulative stroke.
Avoid lateral force exceeding 30N during operation.
| Property | Property Value |
|---|---|
| sku | B06-SDA40X20SB |
