Airtac B06-TCL Battery Dedicated Air Cylinder B06-TCL12X30S
AirTAC B06-TCL12X30S Battery-Powered Cylinder Specifications
- Model: B06-TCL12X30S
- Type: Battery-driven compact cylinder (Double-acting)
- Bore size: 6mm (0.24")
- Stroke: 30mm ±1mm
- Operating pressure: 0.05–0.7 MPa
- Battery voltage: 3.6V DC (Lithium battery CR123A x1)
- Speed range: 50–500mm/s (adjustable via flow control)
- Weight: 210g ±5g (including battery)
- Dimensions: 120mm(L) × 22mm(W) × 22mm(H)
- Body material: Aluminum alloy (anodized finish)
- Piston rod material: Stainless steel SUS304
- Seal type: High-efficiency NBR seals
- Temperature range: -10℃ to 60℃
- Max thrust: 12N (at 0.5MPa)
- Battery life: ≈15,000 cycles (at 25℃)
- Protection rating: IP54 (dust/water resistant)
Self-contained pneumatic actuator designed for wireless automation solutions. Features integrated battery compartment and low-power electromagnetic drive system. The TCL series employs a patented energy-saving circuit that activates only during stroke transitions, enabling extended operation without external power sources. Includes magnetic piston for position sensing compatibility.
- Mobile robotic grippers in AGV systems
- Emergency release mechanisms in security devices
- Portable medical equipment actuators
- Solar-powered agricultural automation
- Wireless laboratory testing apparatus
Installation guidelines:
Maintain 2-3mm lateral clearance for thermal expansion. For vertical mounting,
position battery compartment downward. Replace battery when LED indicator blinks
red (typically every 18-24 months in normal use).
| Property | Property Value |
|---|---|
| sku | B06-TCL12X30S |
