Airtac B06-TCL Battery Dedicated Air Cylinder B06-TCL63X30S
AirTAC B06-TCL63X30S Battery-Optimized Cylinder Specifications
- Model: B06-TCL63X30S
- Series: B06-TCL (Battery Application Series)
- Bore size: Ø63mm
- Stroke: 30mm
- Operation type: Double-acting
- Mounting style: Basic type (Multiple mounting options available via accessories)
- Operating pressure: 0.05–0.8 MPa
- Cushioning: Adjustable air cushion (both ends)
- Temperature range: -20℃ to 80℃
- Piston seal material: NBR + Polyurethane hybrid
- Rod material: Hard chrome-plated steel
- Tube material: Anodized aluminum alloy
- Weight: 2.65 kg (without accessories)
- Dimensions: 156mm(L) × 83mm(W) × 83mm(H) (Full extension length)
- Port size: M5x0.8 (Standard) / NPT1/8 optional
- Rod thread: M12×1.25
- Protection rating: IP54 (Standard) / IP67 with optional wiper
Specialized pneumatic cylinder engineered for battery-powered systems requiring low friction and energy efficiency. Features anti-corrosion treatment on exposed surfaces and optimized seal geometry for reduced air consumption (30% lower than standard models). Includes built-in magnetic field for sensor compatibility.
- Lithium battery production line handling systems
- AGV (Automated Guided Vehicle) lifting mechanisms
- Portable medical device actuators
- Solar-powered agricultural gate controls
- Robotic welding clamp operations
Installation note:
For battery systems, maintain minimum 0.3MPa working pressure to ensure optimal efficiency.
Lubricate with ISO VG32 hydraulic oil if used in high-cycle applications (>500,000 cycles/year).
Vertical mounting requires optional guide bracket (Part# BG-63TCL).
| Property | Property Value |
|---|---|
| sku | B06-TCL63X30S |
