Airtac B52-GZ Non-Copper Shut-Off Valve B52-GZ20008J
AirTAC B52-GZ20008J Copper-Free Shutoff Valve Technical Details
- Full model: B52-GZ20008J
- Valve type: 2-position 2-way normally closed (manual reset)
- Port connection: G1/8 (ISO228 standard)
- Pressure range: 0.2–1.0 MPa (29–145 psi)
- Body material: Anodized aluminum alloy (copper-free design)
- Seal material: Fluororubber (FKM) with PTFE coating
- Operating temperature: -10℃ to 150℃ (14℉ to 302℉)
- Flow coefficient (Cv): 0.65
- Max flow rate: 850 L/min (at 0.5 MPa)
- Actuation force: 15N ±10% (manual lever operation)
- Weight: 328g ±5g
- Dimensions: 78mm(L) × 42mm(W) × 34mm(H)
- Surface treatment: Black electrophoretic coating
- Compliance: RoHS 2.0, REACH SVHC
Industrial-grade shutoff valve specifically engineered for copper-sensitive environments. Features dual-stage sealing with redundant leak prevention, rated for 500,000+ cycles. The copper-free construction prevents catalytic reactions in chemical processes. Includes visual position indicator and torque-limited manual override.
- Ammonia refrigeration systems (copper incompatibility prevention)
- High-purity gas distribution in semiconductor fabs
- Ozone generator piping networks
- Medical oxygen delivery systems
- Corrosive chemical dosing lines
Installation protocol:
Mount in horizontal pipeline orientation only. Apply thread sealant compatible with FKM materials.
Requires upstream 10μm particulate filter. Lever position must align with flow arrow during operation.
Torque limit: 12-15N·m for port connections.
| Property | Property Value |
|---|---|
| sku | B52-GZ20008J |
