Airtac B52-GZ Non-Copper Shut-Off Valve B52-GZ30010
AirTAC B52-GZ Copper-Free Shut-Off Valve B52-GZ30010 Specifications
- Model: B52-GZ30010
- Type: 2-port normally closed manual shut-off valve
- Port size: PT1/4 (G1/4 optional)
- Max working pressure: 1.0 MPa
- Body material: Aluminum alloy with copper-free treatment
- Seal material: FKM (Fluorocarbon Rubber)
- Temperature range: -10℃ to 150℃
- Weight: 320g ±5g
- Dimensions: 68mm(L) × 32mm(W) × 42mm(H)
- Thread torque: ≤3 N·m
- Flow coefficient (Cv): 2.4
- Leakage rate: ≤0.1 mL/min under 0.5 MPa
- Compliance: RoHS 2.0 compliant
Heavy-duty shut-off valve featuring copper-free construction for chemical compatibility, designed for aggressive media applications. The dual-seal structure with precision-machined stem ensures zero leakage during long-term operation. Includes ergonomic lever with 90° rotation lock mechanism for tactile operation feedback.
- Chemical dosing systems in semiconductor manufacturing
- High-purity gas pipelines (O₂/N₂/Argon)
- Coolant control in medical sterilization equipment
- Ammonia refrigeration systems
- Photovoltaic panel etching process lines
Installation guidelines:
Apply PTFE tape on male threads using clockwise wrapping direction.
Avoid side-load forces during piping connection - maximum allowable
lateral force 15N. Perform pressure test at 1.5x working pressure
before initial use.
| Property | Property Value |
|---|---|
| sku | B52-GZ30010 |
