Airtac B52-HLQ Copper-Free Precision Slide Table Cylinder B52-HLQ8X20S
AirTAC B52-HLQ8X20S Copper-Free Precision Slide Cylinder Specifications
- Model: B52-HLQ8X20S
- Type: Guided rod slide cylinder (copper-free design)
- Bore size: 8mm
- Stroke: 20mm
- Operating pressure: 0.15–0.8 MPa
- Cushion type: Adjustable rubber buffer
- Repeat positioning accuracy: ±0.01mm
- Temperature range: -10℃ to 80℃
- Material: Aluminum alloy body with hard anodized surface
- Seal material: Heat-resistant NBR (copper-free formulation)
- Mounting style: Dual side/end mounting holes (M4×0.7)
- Port size: M5×0.8 (Standard Rc1/8 adaptor included)
- Weight: 0.25kg ±5% (without accessories)
- Dimensions: 60mm(L) × 20mm(W) × 20mm(H)
- Rod end thread: M4×0.5 internal thread
- Protection rating: IP54 (dust-proof & splash-resistant)
Ultra-compact guided cylinder featuring copper-free construction for cleanroom and semiconductor applications. Precision ground rods (h6 tolerance) with chromium-plated piston rod (HRC45 hardness) ensure smooth linear motion. Integrated slide rail design reduces moment load by 30% compared to standard cylinders.
- PCB component insertion machines
- Medical device assembly lines
- Optical lens positioning systems
- 3C product testing equipment
- Cleanroom material handling
Operation note:
Requires ISO 8573-1:2010 Class 3 compressed air (max 1mg/m³ oil content).
Lubricate with ISO VG32 turbine oil before initial use. Avoid lateral force exceeding 2N·m.
| Property | Property Value |
|---|---|
| sku | B52-HLQ8X20S |
