Airtac B52-HLQ Copper-Free Precision Slide Table Cylinder B52-HLQ8X30SA
AirTAC B52-HLQ8X30SA Copper-Free Precision Slide Table Cylinder Specifications
- Model: B52-HLQ8X30SA
- Type: Non-rotating guide rod cylinder with copper-free construction
- Bore size: Ø8mm
- Stroke: 30mm
- Operating pressure: 0.05–0.9 MPa
- Cushioning: Adjustable rubber buffers (both ends)
- Piston rod material: Stainless steel (SUS304)
- Tube material: Aluminum alloy (copper-free anodized)
- Seal material: NBR + PU combination
- Temperature range: -10℃ to 80℃
- Max speed: 500mm/s
- Lubrication: Pre-lubricated (Dry operation possible)
- Weight: 280g ±5g
- Dimensions:
- Total length: 118mm (stroke included)
- Body width: 34mm
- Height (with rail): 42mm
- Mounting base: 26×26mm
- ISO standard: 15552 (mounting compatibility)
- RoHS compliance: Yes
Ultra-precision linear actuator with dual linear guide rails and copper-free construction, engineered for contamination-sensitive environments. Features 0.01mm repeat positioning accuracy and integrated T-slot mounting grooves. The chromium-plated guide shaft prevents particulate generation, making it ideal for cleanroom applications.
- Semiconductor wafer handling robots
- Pharmaceutical blister packaging machines
- Optical lens positioning systems
- 3C product assembly automation (phones, tablets)
- Laboratory sample handling systems
Installation note:
Use M3×0.5 mounting screws (max torque 1.2N·m). Maintain perpendicularity within 0.05mm/m during alignment. For vertical mounting, reduce payload capacity by 30%. Requires weekly lubrication (VG32 oil recommended) in high-cycle applications (>1M cycles/year).
| Property | Property Value |
|---|---|
| sku | B52-HLQ8X30SA |
